Width Cm 70

Depth Cm 70 Electric Power kW 9

Height Cm 90

Net weight Kg 110 Standard connection V-Hz 400V 3N~ / 230V 3~ / 50÷60 Hz

1G1BR1E

MANUAL TILT ELECTRIC BRATT PAN,S/S AISI 430

BOTTOM

RANGE FEATURES

Top: 18-10 stainless steel (12/10 mm gauge)

Free-standing structure with top, front panels, sides and

control consoles in 18-10 stainless steel; back panels in

stainless steel.

Top, sides, back, front panels and control consoles with satin

scotchbrite finish.

Side-by-side top configurations with secure fixing between

units.

IPX5 protection rating on all units.

CE approval of all gas products.

FUNCTIONAL FEATURES

• Cooking well with rounded corners, base and walls in 18-10 stainless steel thickness 20/10 mm, with polished interior;

radiant well base in AISI 430 stainless steel thickness 10 mm

• Well dimensions (mm) 630 x 460 x 183 h. Available cooking surface 23.5 dm². Well capacity at drain level: 54 litres. Well

capacity at recommended level: 40 litres.

• Specific output at well base for cooking: 383 W/dm².

• Well with outlet spout specially shaped to enable product drainage without overflowing.

• Lid mounted on spring-loaded hinges.

• Even well base heating with armoured electrical heating elements fitted beneath the well base. Heating output controlled by

thermostat switch.

• Manual well tilting with handwheel operating through a lead screw mounted on front of appliance. Safety switch cuts off

power to well in raised position.

• Back slot with perimeter edge with enamelled guard.

• Heat-resistant knobs with screen printed markings and reference index printed on control console.

• Height adjustable floor-mounted feet in 18-10 stainless steel - floor clearance 180 mm, with non-scratch sole in insulating

plastic material.

TECHNICAL FEATURES

• AISI309 stainless steel armoured heating elements. Thermostat switch temperature control. Operating temperature: 100°C-

270°C.

• Manual resetting safety thermostat.

• Easy access to all controls and parts from front of appliance.
