TEFCOLD DB200S-I [12/31] Defrosting

Thermostat

The thermostat is placed in the back up the cabinet, see fig. 2.0

Fig. 2.0

The thermostat can be adjusted with a scale of 1-6, which is equivalent to approximately 2-12°C

Optimal setting will in most cases be 3-4.

The cooling system can be disconnected at a setting at 0.

Defrosting

The cabinet defrosts automatically. Defrosted water runs to a container placed in the compressor

compartment and evaporates.

Moving the shelves

The shelf guides is moved by squeezing them together and lifting them upwards at the same time.

Check that all 4 shelf guides are placed in the same height before placing the shelf in the cabinet.

Door reversal (DB125H only)

Remove the 3 screws in the bottom hinge and let the door slide out of the top hinge.

Move the top hinge to the opposite side and remount the door and bottom hinge.

Fan

Light switch

Thermostat
