Form No. MPWSRP-0115
3
Parts for Models MPWS-36 and MPWS-45
The shaded areas contain information for International models only.
* Units with Date Code 1450 or earlier, use P/N 04.25.519.00.
† Units with Date Code 1450 or earlier, use P/N 04.25.518.00.
NOTE: The last four digits in a ten digit numerical serial number are the manufacturing date code.
Example: Serial number 9625061331 has a date code of “1331” which indicates the following:
Week Thirty-One
1331
Year 2013
Item Description Part No. Qty.
1 Top Cover
MPWS-36 04.25.515.00 1
MPWS-45 04.25.514.00 1
2 Back Cover
MPWS-36 * 04.25.677.00 1
MPWS-45 † 04.25.676.00 1
3 Side Cover, Left Side 04.25.505.00 1
4 Legs, Adjustable 4" 05.30.007.00 4
5 Element, Blanket
MPWS-36
120/208 and 230 V 02.05.220.00 1
120/240 V 02.05.896.00 1
MPWS-45
120/208 and 230 V 02.05.218.00 1
120/240 V 02.05.895.00 1
6 Thermostat R02.16.066.00 1
7 Potentiometer 02.01.117.00 2
8 Relay 02.01.098.00 2
9 Terminal Block R02.15.046.00 1
10 Rocker Switch 02.19.015.00 1
11 Cord Grip 02.20.290.00 1
12 Power Cord
L14-20P (120/208 and 120/240 V) 02.18.132.00 1
No Plug (230 V) 02.18.103.00 1
13 Fan, Cooling 02.12.010.00 2
14 Label, Control 07.03.627.00 1
15 Knob, Infinite 05.30.042.00 2
16 Knob, Thermostat 05.30.039.00 1
17 Solid State Infinite R02.01.102.00 2
18 Side Cover, Right Side 04.25.503.00 1
19
Element, Ceramic
120/208 and 230 V 02.07.009.00 6
120/240 V 02.07.023.00 6
20
Guard, Ceramic Element 04.25.362.00 6
Item Description Part No. Qty.
21
Bulb
120/208 and 120/240 V 02.30.043.00 4
230 V 02.30.058.00 4
22
Lamp Holder, Dual 02.30.047.00 1
23
Lamp Holder, Single 02.30.051.00 2
24
Pan Stop
MPWS-36 04.25.517.00 1
MPWS-45 04.25.516.00 1
25
Scoop Holder 04.25.413.00 1
26
Bag and Tong Holder 04.25.416.00 1
27
Pan, Stainless Steel 04.25.528.00 1–2
28
Pan, Plastic
1/4 Size 04.09.227.00 1
1/2 Size 04.09.225.00 1
29
Lid, Plastic Pan (not shown)
1/4 Size 04.09.233.00 1
1/2 Size 04.09.226.00 1
30
Divider 04.25.545.00 3–4
31
Ribbon, 6-Pleat Bag/Box 04.25.315.00 1–4
32
Trivet 04.25.501.00 1–2
33
Ribbon, 4-Pleat Box 04.25.356.00 1–4
34
Ribbon, 5-Pleat Bag 04.25.350.00 1–4
35
Riser, Angled 04.25.520.00 1–6
36
Trivet Stand
MPWS-36 04.25.571.00 1
MPWS-45 04.25.572.00 1
37
Large Fry Trivet
MPWS-36 04.25.544.00 1
MPWS-45 04.25.547.00 1
Wiring Diagram
120/208 and 120/240 V 10-01-483
230 V 10-01-1016
