Sagi KUB2 (внутренний агрегат) Брошюра онлайн

UNIVERSAL Range

Refrigerated counter 70 cm GN 1/1

Lt 390

Range plus:

* Quality performances

* Ergonomics and design

* Peak reliability and energy saving

Commercial code

Kw 0,55 - Standard connection: V-Hz 230V 1N-/50Hz

Refrigerant capacity: 475 W at evaporation temperature of -10°C. Ventilated refrigerating system with

protected finned evaporator positioned outside the chamber and electric fans. Refrigerant fluid R404A.

Temperature range 0/+10°C even at a room temperature of +43°C (Climate Class 5, room +40°C and

40% R.H.). Automatic simple stop defrosting and evaporation of the condense drain. The appliance’ s

outstanding reliability is also assured by the IP24 protection of its functional elements. Noise level <70

dBA.

0/+10°C

KUB2

Temperature range

Technical features

External size

Exterior/interior: AISI 304 stainless steel one-piece structure. Suitable to GN 1/1 containers. Doors, side

panels and control console with Scotchbrite finish. Polyurethane insulation: 60 mm thick, density 40

kg/m³. Automatic condensation evaporation. CE certification. Stainless steel one-piece structure with

CFC-free polyurethane injection, 60 mm thick. Model without worktop, preset to be assembled with

continous work surfaces. Control panel with digital thermometer-thermostat and ON/OFF switch. The

cooling unit pulls out to simplify routine cleaning of the condenser. “U”-flow air circulation to assure

peak cooling unit reliability. Refrigerated compartment with 2 doors and 2 drawers. Gross capacity: 390

lt. Enclosed drawer with three-stage telescopic runners allowing containers to be lifted out vertically.

Lower drawer: 305x548x195 mm, gross capacity: 32,6 lt. Upper drawer: 305x548x147 mm, gross

capacity: 24,6 lt.

M³: 1 / Lt 390 / Kg 119

Insulated door equipped with removable magnetic gaskets that assure an optimum closing. Self-closing

device for openings less than 90°. Depth with open doors 106 cm. Stainless steel handle. Outer

evaporator, pressed plate, washing hole for the cleaning of the cell. Easy removable AISI 304 stainless

steel racks to support grids/containers. Each compartment is equipped with 1 pair of stainless steel

runners and 1 grid GN 1/1. AISI 304 stainless steel height-adjustable feet (h max 900mm, min. 850 mm).

Optional accessories: kit temperature-recorder with printer, couple of stainless steel runners to support

containers/grids, stainless steel wire basket GN 1/1, plastic coated or stainless steel grids GN 1/1,

swivelling wheels.

Electric power

Volume/ Net weight

l. 185x d.70 x h. 84 cm

Functional features

Ufficio Marketing
