Model Number MC2502FG MC3002FG MC3502FG
Power Requirements 200-240VAC, 1Ph 200-240VAC, 1Ph 200-240VAC, 1Ph
Power Consumption 5000W (max, 2x2500W) 6000W (max, 2x3000W) 7000W (max, 2.3500W)
BTU Comparison 2 x 22,000 BTU 2 x 26,000 BTU 2 x 31,000 BTU
Voltage 200-240VAC, 50/60 Hz 200-240VAC, 50/60 Hz 200-240VAC, 50/60 Hz
Amperage 22A (max) 26A (max) 32A (max)
Power Range 100-2500W per burner (hob) 100-3000W per burner (hob) 100-3500W per burner (hob)
Temperature Range 85-500°F / 30-260°C 85-500°F / 30-260°C 85-500°F / 30-260°C
Dimensions (in) 30.42” x 13.85” x 4.98” 30.42” x 13.85” x 4.98” 30.42” x 13.85” x 4.98”
Dimensions (mm) 772 x 351 x 126 772 x 351 x 126 772 x 351 x 126
Weight 31.2 lbs / 14.2 kg 31.2 lbs / 14.2 kg 31.2 lbs / 14.2 kg
Packaged Weight 45 lbs / 20.4 kg 45 lbs / 20.4 kg 45 lbs / 20.4 kg
Packaged Dimensions (in) 36” x 18” x 12” 36” x 18” x 12” 36” x 18” x 12”
Packaged Dimensions (mm) 914 x 457 x 305 914 x 457 x 305 914 x 457 x 305
Power Cord Length 6 ft / 1.8 m 6 ft / 1.8 m 6 ft / 1.8 m
Plug Type NEMA 6-30Pin US/Canada, country specific elsewhere NEMA 6-50P
Warranty 36 months limited parts and labor in US and Canada only - see statement for details
Specifications
CookTek Induction Systems, LLC
156 N. Jefferson St. Ste 300
Chicago, IL 60661-1436, USA
www.cooktek.com
Tel: 1.312.563.9600 Fax: 1.312.432.6220
Toll Free: 1.888.COOKTEK (266.5835)
Toll Free Fax: 1.888.COOKFAX (266.5329)
MCxx02FG 12157_A USINTL
MC2502FG, MC3002FG, MC3502FG
APOGEE
TM
COUNTERTOP DOUBLE BURNER (HOB) COOKTOP
Note: Ambient air should not exceed 50˚C/122˚F. Dedicated circuit required. Many local codes exist, and it is the Owner and Installer’s responsibility to comply with those codes. CookTek
continually improves its products and reserves the right to change or improve specifications without notice.
• Dedicated circuit required
• Requires maximum (do not exceed) ambient temperature of 50˚C/122˚F
• Cooling clearance: 2” (55mm) from combustable materials
APOGEE
TM
COUNTERTOP DOUBLE
BURNER (HOB) COOKTOP
MC2502FG, MC3002FG, MC3502FG
Dimensions
inches mm
A 30.42 772
B 13.85 351
C 4.98 126
