13 Technical data
Installer and user reference guide
59
RXYSQ8~12TMY1B
VRV IV-S system air conditioner
4P404225-1A – 2015.11
Specification RXYSQ8 RXYSQ10 RXYSQ12
▪ Sound power
(f)
73dBA 74dBA 76dBA
▪ Sound pressure
(g)
55dBA 55dBA 57dBA
Refrigerant
▪ Type R410A
▪ Charge 4.5kg 7kg 8kg
Refrigerant oil FVC68D
Safety devices High pressure switch
Fan driver overload protector
Inverter overload protector
PCB fuse
(a) Nominal cooling capacities are based on:
Eurovent: Indoor temperature: 27.0°CDB, 19.0°CWB. Outdoor temperature: 35°CDB. Eurovent2015. Power input indoor units excluded.
T1: Indoor temperature: 26.7°CDB, 19.4°CWB. Outdoor temperature: 35°CDB. AHRI1230:2010. Power input indoor units (duct type) included.
T3: Indoor temperature: 29.0°CDB, 19.0°CWB. Outdoor temperature: 46°CDB. ISO15042:2011. Power input indoor units (duct type) included.
T2: Indoor temperature: 26.6°CDB, 19.4°CWB. Outdoor temperature: 48°CDB. AHRI1230:2010. Power input indoor units (duct type) included.
(b) Nominal and maximum heating capacities are based on indoor temperature 20°CDB, outdoor temperature 7°CDB and 6°CWB, equivalent
refrigerant piping: 5m, level difference: 0m.
(c) Actual number of units depends on the indoor unit type (VRVDX, RADX, ...) and the connection ratio restriction for the system (50%≤CR≤130%).
(d) Nominal at 230V.
(e) Sound values are measured in a semi-anechoic room.
(f) Sound power level is an absolute value that a sound generates.
(g) Sound pressure level is a relative value depending on the distance and acoustic environment. For more details, refer to sound level drawings in
the technical data book.
Electrical specifications
Specification RXYSQ8 RXYSQ10 RXYSQ12
Power supply
▪ Name Y1
▪ Phase 3N~
▪ Frequency 50Hz
▪ Voltage 380-415 V
Current
▪ Nominal running current (RLA)
(a)
9.6A 10.7A 13.4A
▪ Starting current (MSC)
(b)
≤MCA
▪ Minimum circuit amps (MCA)
(c)
18.5A 22A 24A
▪ Maximum fuse amps (MFA)
(d)
25A 32A
▪ Total overcurrent amps (TOCA)
(e)
16.5A 25A 27A
▪ Full load amps (FLA)
(f)
1.4A
Voltage range 380-415V +/– 10%
Wiring connections
▪ For power supply 5G
▪ For connection to indoor unit 2 (F1/F2)
Power supply intake Both indoor and outdoor unit
(a) RLA is based on indoor unit temperature 27°CDB and 19°CWB, outdoor temperature 35°CDB.
(b) MSC=the maximum current during startup of the compressor. VRV IV-S uses only inverter compressors. MCA must be used to select the correct
field wiring size. The MCA can be regarded as the maximum running current.
(c) MCA must be used to select the correct field wiring size. The MCA can be regarded as the maximum running current.
(d) MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
(e) TOCA means the total value of each OC set.
(f) FLA=nominal running current fan. Voltage range: units are suitable for use on electrical systems where voltage supplied to unit terminal is not
below or above listed range limits. Maximum allowable voltage range variation between phases is 2%.
