Lainox REV051M [2/3] Rev 051 m tav a

ed. 0713

ATTENZIONE: PER ORDINARE I RICAMBI, SPECIFICARE SEMPRE IL MODELLO DI FORNO ED IL NUMERO DI MATRICOLA

ATTENTION: WHEN ORDERING SPARE PARTS, PLEASE ALWAYS SPECIFY THE OVEN MODEL AND THE SERIAL NUMBER

ATTENTION: POUR COMMANDER DES PIECES, MERCI DE SPECIFIER TOUJOURS LE MODELE DU FOUR ET LE NUMERO DE SERIE

ACHTUNG: UM ERSATZTEILE ZU BESTELLEN, BITTE IMMER OFEN-MODELL UND SERIENNUMMER GEBEN.

POS. COD. Pz. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPCIÓN

1 R17201110 1 ASS.CERNIERA SUP.PORTA REC-REV-REP 2011

UPPER HINGE CHARNIERE SUPERIEUR OBERES SCHARNIER BISAGRA SUPERIOR

2 R18200600 1 ASS.FARFALLA M_042/051 REV M CHAMBER VENT PLATE ENTFEUCHTUNGSSCHIEBER DISQUE EVENT DISCO RESPIRADERO

3 R10201700 1 ASS.FILTRO DI SCARICO D.76/44.5 M/106-11 DRAIN FILTER FILTRE ENCEINTE ABFLUSSFILTER FILTRO DESAGUE

4 R58003560 1 ASTA SFIATO REV 051/071/101 M CHAMBER VENT ROD BARRE COMMANDE EVENT SCHIEBERACHSE EJE RESPIRADERO

8 R65110200 1 E.V. 1 VIA 220V 50HZ X J.G.CON ATTACC SOLENOID VALVE 220V 50HZ ELECTROVANNE 220V 50HZ MAGNETVENTIL 220V 50HZ ELECTROVALVULA 220V 50HZ

9 R75300150 1 GRIGLIA VENTILATORE D.170 FAN GUARD GRID D.170 GRILLE VENTILATEUR D.170 VENTILATORSCHUTZGITTER D.170 REJILLA VENTILADOR D.170

10 R65090170 1 INVERSORE CICLICO 8' 3 CAMME REVERSING SWITCH INVERSEUR POLWENDER INVERSOR CICLICO

11 R65270300 2 LUCE SPIA GIALLA ALPHATECH SL 656 TZB ORANGE INDICATING LIGHT LAMPE TEMOIN ORANGE ORANGENE KONTROLLAMPE LAMPARA PILOTO NARANJA

12 R65270320 1 LUCE SPIA VERDE ALPHATECH SL 656 TZA GREEN INDICATING LIGHT LAMPE TEMOIN VERT GRUENE KONTROLLAMPE LAMPARA PILOTO VERDE

13 R69030130 3 MANOPOLA BLU/BLU D.42 KNOB KIT POIGNEE COMMANDE DREHKNOPF PULSADOR MANETA

14 R65260540 1 MICRO PORTA DOOR SWITCH MICRO PORTE TUERSCHALTER MICRO PUERTA

15 R65220091 1 MORSETTIERA LX2E (TIPO 2) NEW TERMINAL BOARD BORNIER KLEMMLEISTE REGLETERA

16 R65041040 1 MOTORE 1F.125Win-75Wout 2VEL C/COND. FIR MOTOR MOTEUR MOTOR MOTOR

17 R69010260 1 NASELLO 1 STEP 6303-020022

23 R65270510 1

PORTALAMPADA STAGNO ALPHATECH

77.705.U10

WATERPROOF LIGHT SOCKET DOUILLE ETANCHEE DICHTE LAMPEHALTERUNG PORTALAMPARA ESTANCO

24 R65240200 1 PRESSACAVO V-TEC 21 NERO FAIRLEAD PRESSE CABLE ZUGENTLASTUNG PRENSACABLES

25 R65260520 1

PULSANTE COMANDO UMIDIFICATORE TIPO

SPL60

HUMIDIFIER PUSH BUTTON TOUCHE HUMIDIFICATEUR BESCHWADUNGSDRUCKTASTE PULSADOR UMIDIFICADOR

26 R65011730 1 RESIST.7000W230V CAM. ALPHA INCOLOY800 HEATING ELEMENT RESISTANCE HEIZKOERPER RESISTENCIA

27 R62090788 1 RIDUZIONE INTER.DRITTA ø10-ø6 PM201006E REDUCTION REDUCTION VERRINGERUNG REDUCCION

28 1 TASTIERA PLATE PLAQUE BEDIENUNGSFOLIE TARJETA

34 R65090110 1

TIMER ELETTROM. 120’ C/POS. M.

14000F3120ME0 DALLA SETTIMANA 27/2013

TIMER FROM WEEK 27/2103 MINUTERIE DU SEMAINE 27/2013 ZEITSCHALTUHR VOM WOCHE 27/2013 TEMPORIZADOR DEL SEMANA 27/2013

35 R75400410 1 VENTOLA D.180X77/12 50HZ P.D. FAN TURBINE LUEFTERRAD PALA VENTILADOR

36 R17102610 1 PORTA COMPLETA REV-RGV051 LX DOOR ASSEMBLY PORTE COMPLETE TUER KOMPLETT PUERTA COMPLETA

R17105400 1 PORTA COMPLETA SERIGRAFATA REV-RGV051 AT DOOR ASSEMBLY PORTE COMPLETE TUER KOMPLETT PUERTA COMPLETA

37 R58005500 1 FLANGIA GUARNIZIONE MOTORE MOTOR GASKET BRASS FLANGE BRIDE JOINT MOTEUR FLANSCH F. MOTORDICHTUNG BRIDA JUNTA MOTOR

38 R65110500 1 REGOL. PORT. MARR. ATCH. 10Lt/h 10 LT/H WATER FLOW REDUCER REGULATUER DE DEBIT 10 LT. DURCHFLUSSMONDERER 10L/STD. REGULADOR DE CAUDAL 10 LT.

39 R70010140 1 GUARNIZIONE SILICONE ROSSO 76x40,3x3 RED GASKET 76x40,3x3 ROUGE JOINT 76x40,3x3 ROTEN DICHTUNG 76x40,3x3 JUNTA ROJA 76x40,3x3

40 R65190080 1 CONDENSATORE 5 µF CAPACITOR CONDENSATEUR KONDENSATOR CONDENSADOR
