8
1. CONSTRUCTION VIEWS (EXTERNAL VIEWS)
1-1. Indoor Unit
Model:
MMK-AP0073H (IN), MMK-AP0093H (IN), MMK-AP0123H (IN),
MMK-AP0153H (IN), MMK-AP0183H (IN), MMK-AP0243H (IN)
Wireless remote controller
Remote controller holder
1050
50
56 24
82 26
132 568 200 150
72 78
228
320
204
163
132 786
235
47 215.5 262.5 262.5 153.5 109
235
215 215
85
23
132
320
40
40
50
73.5
7
50
73.5
7
Front panel
Air filter
Heat exchanger
Installation plate hanger
Installation plate hanger
Connecting pipe (0.39m)
(07, 09, 12 series; 9.5mm
15, 18 series; 12.7mm
24 series; 15.9mm)
Drain hose
(0.5mm)
Connecting pipe (0.44m)
(07, 09, 12 series; 6.4mm
15, 18 series; 6.4mm
24 series; 9.5mm)
Air inlet
Knock out system Knock out system
Hanger
Hanger
Center line Instrallation plate outline
Hanger
