(3) Installation of suspension bolt
• This is the same as for discharge/suction duct type.
Follow instructions for discharge/suction duct type.
(4) Preparation for installing indoor unit
• Remove the screw
of the electric box and then
remove electric box.
• Relocate the electric box with lead wires kept
connected. Ensure the lead wire is positioned at the
upper side, and hook the claw of electric box to side
plate. Then fi x the electric box to the bottom of the
indoor unit using 4 screws.
• Install 4 suspension clamps at both sides of indoor unit,
2 clamps at each side, using 8 tapping screws
.
(Since sizes of left and right clamps are different for
certain parts, refer to diagram on the right.)
• Install chamber of discharge of unit side on the indoor
unit using 10 tapping screws.
(3) Installation of suspension bolt
• This is the same as for discharge/suction duct type.
Follow instructions for discharge/suction duct type.
(4) Preparation for installing indoor unit
• Remove the screw
of the electric box and then
remove electric box.
• Relocate the electric box with lead wires kept
connected. Ensure the lead wire is positioned at the
upper side, and hook the claw of electric box to side
plate. Then fi x the electric box to the bottom of the
indoor unit using 4 screws.
• Install 4 suspension clamps at both sides of indoor unit,
2 clamps at each side, using 8 tapping screws
.
(5) Change of suction opening and fi lter
position from bottom to back side
• Remove the fi lter from the bottom side of indoor
unit by removing 8 screws from the fi lter holders.
• Remove 6 screws from the back plate of the
indoor unit.
(6) Installation of indoor unit
• Set nut and washer on suspension bolt and hook it
to suspension clamp by lifting the indoor unit.
• Make sure that indoor unit is kept at a straight level
using a level or vinyl hose with water.
• Fix the indoor unit so that the space between
bottom surfaces of ceiling and indoor unit is 58mm.
2.5 Connection of the drain pipe
(1) Securely glue connection part of drain hose and
PVC pipe, using PVC adhesive.
(2) Make sure to wrap generally-available insulator (10m
or more of foamed polythene) around drain hose
inside the house for insulation.
(3) To check the drain and water leakage, after
connecting power:
• Add water to the water pan of the indoor unit as
shown below.
(4) Test run method
Turn power on.
Remove lid of electric box and set the drain pump
test run switch to TEST.
After checking the drainage, return the switch to
NORMAL.
(5) Perform test running of drain pump to check
drainage operation.
2.6 Preparation of pipe
• Use a pipe cutter to cut the copper pipe.
• Before fl aring, please put on the fl are nut.
• Please use exclusive tool.
• Then install the back plate at the bottom of indoor
unit using 6 screws.
• Install fi lter at backside of indoor unit by fi xing it
with fi lter holders (4 portions) using 8 screws.
• Chamber of discharge grille
(5) Installation of indoor unit
• Set nut and washer on suspension bolt and hook it to
suspension clamp by lifting the indoor unit.
• Make sure that indoor unit is kept at level using a level
or vinyl hose with water.
• Fix the indoor unit so that the space between bottom
surfaces of ceiling and indoor unit is 58mm.
• Select the indoor unit position, fi xing direction of air
outlet so that cool/hot air reaches all the room.
• Do not allow any obstacle to block air fl ow within
1m of suction grille.
• Use M10 bolt for suspension.
• Opening of ceiling and suspension bolt position are
as shown on the left.
• Before installing the indoor unit, prepare opening
960mm x 520mm on ceiling, and 868mm x 152mm
on wall and arrange drain pipe, refrigerant pipe and
connecting cord in their installation positions.
• For fi nishing of opening on ceiling and wall arrange
with builder in detail.
• Be sure to reinforce furring of ceiling (frame: ceiling
joist and joist supporter) to maintain level of ceiling
and prevent vibration of ceiling plate.
Refer to the installation manual of optional parts for
installation of:
--Discharge grille chamber
--Suction grille
--Discharge grille
--Flexible duct
(1) Installation fi gure
(2) Opening on ceiling and suspension bolt position
INSTALLATION OF NON DUCT TYPE
CAUTION
!
• Install the indoor unit in a straight level. If the
indoor unit is inclined, water may leak.
• If space between bottom surfaces of indoor
unit and ceiling is not correct, there may be a
gap between grille and ceiling surface, with
consequent leakage of condensed water.
• If gluing of drain hose and PVC pipe is too weak,
water leakage may occur.
• If checking of drainage is omitted, water leakage may
occur.
• If drain pump test run is left set to TEST, drain pump
may malfunction.
CAUTION
CAUTION
!
!
• Be sure to install the indoor unit level. If the
indoor unit is inclined, water may leak.
• If space between bottom surfaces of indoor
unit and ceiling is not correct, there may be a
gap between grille and ceiling surface, with
consequent dropping of condensed water.
• Jagged edge will cause leakage.
• Point the side to be trimmed downwards during
trimming to prevent copper chips from entering
the pipe.
CAUTION
CAUTION
!
!
Ceiling
Above 200
Above 300
Front view
Plan view
Side view
Above 330
Above 300
Opening on ceiling
Suspension bolt
(M10: Local purchase)
Reinforcement
Suspension bolt
position 740
Indoor unit
Chamber of discharge
of unit side
Screw
A level
Opening on ceiling
Suspension bolt (M10)
(Local purchase)
Hexagon nut (M10)
(Local purchase)
Washer
(Local purchase)
58mm
Ceiling
(Unit : mm)
(Unit : mm)
Opening on ceiling 960
Opening on ceiling 520
Opening for discharge
Opening for discharge
Suspension bolt 347
Suspension bolt 790
Air deflector
Indoor unit
Discharge duct
Discharge duct
Discharge grille
Discharge grille
Above 300
Above 650
Above 300
Above 800
Above 300
Suction grille
Opening for discharge 960
Opening for discharge
Wall surface
Above 650
52 or less
Above 300
45 or less
Suspension bolt
Suspension bolt
about 170
Suspension bolt 790
Indoor unit center
Indoor unit center
(View from the front)
(View from ceiling)
(Discharge side)
Front view
Plan view
Indoor unit
Back plate
(1) Bottom side suction opening
Filter holders
Filter holders
Filter
Filter
Back plate
Indoor unit
(2) Back side suction opening
A level
Opening on ceiling
Suspension bolt (M10)
(Local purchase)
Hexagon nut (M10)
(Local purchase)
Washer
(Local purchase)
58mm
Ceiling
Drain hose
PVC pipe
PVC adhesive
Pump of oil stove
Pail
Water
Water pan
Trimming tool
Copper pipe
Die
Die
Copper pipe
Drain pump
Drain pump test switch (SW503)
Test Normal
Left side
suspension clamp (2)
Right side
suspension clamp (2)
Screw
3
Screw
8
Screw
3
Screw
8
Left side
suspension clamp (2)
Right side
suspension clamp (2)
Screw
3
Screw
8
Screw
3
Screw
8
