WL5/1-2 Rev.00 05-2013 pag. 53
7.5 – CONTROLS
As a whole the appliance is controlled by an electronic board (PCB).
As soon as the appliance is connected to the electricity supply, the display lights up completely for a lamp test lasting a
few seconds. At the end of the lamp test, the display goes automatically to how it was before the appliance was switched
off, for example if a cycle was in progress at that time, the cycle will restart from the point it was interrupted.
With the PCB OFF, the display is not lit except for the icon . Upon pressing key the icon goes out and the
display comes ON showing the temperature in the cabinet.
With the PCB OFF and the keypad active, press the key to switch the LED lights inside the appliance on and off. If
the appliance is also provided with an adjustable light kit, with the PCB OFF and key lit, the intensity of the LED
lights can be lowered using the remote control (provided) to the point of switching them off (using the - key). Always with
the remote control (using the + key), the lights can be switched back on.
Use the commands on the touch panel, helped by the indications on the display, to activate the various appliance
functions.
If the buzzer sounds for any reason whatsoever, it may be muted by simply pressing any key.
Whatever the status of the appliance, after having activated the keypad, pressing the key puts the PCB to OFF.
7.6 – PREPARING FOR USE
Before using the appliance, the inside of the cabinet should be thoroughly cleaned.
When switching on after installation or if the appliance has not been used for a long time, it is a good rule to let it operate
empty until the set temperature has been reached.
To get the best performance from the Wine Library, arrange the bottles so that air can circulate properly: do not obstruct
the refrigerating unit intake, do not lay the bottles on each other and distribute the load evenly.
Do not load the appliance with more than the allowed quantities, do not put in bottles having a temperature above the
indicated design room temperature (+25°C) and avoid pointlessly opening the door otherwise the efficiency of the
refrigerating unit will be reduced.
