La Nordica Rossella R1 Liberty [15/48] Fire safety

ROSSELLA R1 BII - LUNA BII

1191015 - IT - EN - DE - FR 15

4. FIRE SAFETY

When installing the product, the following safety measures must be observed:

a) In order to ensure sufcient thermal insulation, respect the minimum safety distance from objects or furnishing components

ammable and sensitive to heat (furniture, wood sheathings, fabrics. etc.) and from materials with ammable structure (see

Picture 4 at page 40 - A). All the minimum safety distances are shown on the product data plate and lower values must not

be used.

b) In front of the furnace door, in the radiation area there must be no ammable or heat-sensitive objects or material at a distance of

and at least 30 cm at the sides, in addition to the opening of the loading door (see Picture 4 at page 40 - B).

d) No ammable components (e.g. wall units) must be present above the product.

The Product must always operate exclusively with the ash drawer inserted. The solid combustion residues (ash) must be collected in a

sealed, re resistant container. The Product must never be on in the presence of gaseous emissions or vapours (for example glue for

linoleum, petrol etc.). Never deposit ammable materials near the Product.

During combustion, thermal energy is released which leads to considerable heating of the surfaces, doors, handles, controls, glass parts,

the ue gas pipe and possibly the front part of the appliance. Avoid contact with these elements unless using suitable protective

clothing or accessories (heat resistant gloves, control devices).

Ensure children are aware of these dangers and keep them away from the furnace when it is on.

When using the wrong fuel or one which is too damp, due to deposits present in the ue, a ue re is possible.

d) Request the immediate intervention of the Fire Brigade

DO NOT PUT OUT THE FIRE WITH WATER.

When the ue stops burning, have it checked by a specialist to identify any cracks or permeable points.

5. TECHNICAL DESCRIPTION

The chimney stoves of La NORDICA are suitable to heat living spaces for some periods. As fuel, wood logs are used. The appliance

works as an intermittent operating appliance.

The stove is made of sheets of metal in galvanized steel, enamelled cast iron and, depending on the model, thermo radiant ceramics or

soapstones.

The hearth is internally sheathed with single sheets in cast iron and inside it there is a turning and extractable grate; the back side is

extractable. Thanks to some calibrated holes made over that side, the supply of pre-heated air inside hearth is guaranteed and having, in

• Irradiation (30%): through the panoramic glass and the external hot surfaces of the stove, the heat is radiated into the environment.

( See chapter CALCULATION OF THE THERMAL POWER).

• Do not install the appliance in rooms containing collective ventilation ducts, hoods with or without extractor, type B gas appliances,

heat pumps, or other appliances that, operating at the same time, can put the room in depression (ref. UNI 10683 standard).

• Make sure that the ue and the pipes to which the appliance will be connected are suitable for its operation. It is not allowed the

connection of various appliances to the same chimney.

• The diameter of the opening for connection to the chimney must at least correspond to the diameter of the ue gas pipe. The

opening must be equipped with a wall connection for the insertion of the exhaust pipe and a rosette.

• The installation must be appropriate and has to allow the cleaning and maintenance of the product and the ue.

La NORDICA S.p.A. declines all responsibility for damage to things and/or persons caused by the system. In addition, it is not
