• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

• Children should be supervised to ensure that they do not play with the applianc.

Disposal of the appliance.

• This marking indicates that this product should not be disposed with other household

wastes throughout the EU. To prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse

of material resources. To return your used device, please use the return and collection

systems or contact the retailer where the product was purchased. They can take this

product for environmental safe recycling.

-7-

1. Structure

2. Operation Guide

1. Insert the power plug into the power socket. Make sure the power socket is

220V~240AC / 50Hz or 100V~120V / 60Hz

2. Allow the empty wine cooler to operate for approx. one hour. This will allow the wine

cooler to reach the desired temperature.

3. Fill the wine cooler with your choice of wine bottles. Allow 1-2 hours of operation

before the bottles reach the desired temperature.

1.-UPPER HINGE 2. -LIGHT COVER 3.- FAN MASK 4.- FAN MASK 5.- SHELF 6.- FOOT 7.-WATER TRAY 8.-LOWER

HINGE 9. -LOWER DOOR 10.- CONTROL BOARD 11.- UPPER DOOR 12.- CONTROL BOARD 13.-LED WINDOW

14 .-TEMPERATURE KEY 15. -TEMP DOWN KEY 16.- LIGHT SWITCH 17.-UPPER DOOR HANDEL 18.-BOTTOM DOOR

HANDEL

Your CV021-2T CAVANOVA wine cooler has two separate temperature zones. The top cabinet has a range from 7 to 18 º C

and the bottom area can reach from 10 to 18 º C. Making it ideal for red and white wines.

To raise or lower the temperature just hit the display (Diagram) ^ ^ or by selecting the desired temperature
