![Cavanova CV028C-NS [7/9] Lamp cover 2 shelf 3 fan mask 4 adjustable foot 5 lower hinge 6 magnetic seal 7 door 8 plastic bracket for display board 9 upper hinge](/img/pdf.png)
Cavanova CV028C-NS [7/9] Lamp cover 2 shelf 3 fan mask 4 adjustable foot 5 lower hinge 6 magnetic seal 7 door 8 plastic bracket for display board 9 upper hinge
![Cavanova CV028C-NS [7/9] Lamp cover 2 shelf 3 fan mask 4 adjustable foot 5 lower hinge 6 magnetic seal 7 door 8 plastic bracket for display board 9 upper hinge](/views2/1334596/page7/bg7.png)
1. Structure
Setting The Temperature Control
The temperature inside the wine cooler is dependant on the ambient temperature (room temp.)
outside the wine cooler. The cooler temperature can range between 12~18? . This is based on an
ambient room temperature of 25°C. The inside temperature can be altered by the temperature
adjustor on the upper side of the inside cabinet.
2. Operation Guide
1. Insert the power plug into the power socket. Make sure the power socket is
220V~240AC / 50Hz or 100V~120V / 60Hz
2. Allow the empty wine cooler to operate for approx. one hour. This will allow the
wine cooler to reach the desired temperature.
3. Fill the wine cooler with your choice of wine bottles. Allow 1-2 hours of operation
before the bottles reach the desired temperature.
3. Troubleshooting
1. Lamp cover
2. Shelf
3. Fan mask
4. Adjustable foot
5. Lower hinge
6. Magnetic seal
7. Door
8. Plastic bracket for display board
9. Upper hinge
1
1
2
3
4
5
6
7
8
9
Symptoms Possible cause Solutions
The wine cooler
does not work.
There is a power failure.
A house fuse has blown.
Ensure the cooler is plugged in and the
power socket is turned on.
Replace the broken fuse in your meter box.
Wine cooler is not
reaching the
desired
temperature
The cooler is placed too close to a
heat source
No sufficient ventilation
The door is opened too frequently or
for a long period of time
Keep the cooler away from sunshine or
other heat sources
Place the wine cooler in good ventilation
and keep any items away from the fans.
Close the door tightly and do not open the
door too frequently or for a long period of
time.
Frost forming in
the wine cooler
Too much humidity. The ambient
temperature is too low
Unplug to defrost, plug again after the
frost thaws.
-6-
