HEATING CAPACITY
V = 1750 m
3
/h
Tw1/Tw2 = 90/70
o
C
Tw1/Tw2 = 60/40
o
C
Tp1
PT
Qw
∆pw
Tp2
PT
Qw
∆pw
Tp2
°C
kW
l/h
kPa
°C
kW
l/h
kPa
°C
0
19,4
873
5,9
31,3
10,9
473
2,1
17,2
5
18,3
806
5,1
34,4
9,4
409
1,6
20,1
10
16,8
741
4,4
37,5
7,9
345
1,2
23,0
15
15,3
676
3,7
40,5
6,4
280
0,8
25,7
20
13,9
613
3,1
43,5
4,8
210
0,5
28,1
Tw1/Tw2 = 80/60
o
C
Tw1/Tw2 = 50/40
o
C
0
16,9
741
4,5
26,7
10,9
945
7,6
17,2
5
15,4
676
3,8
29,7
9,4
820
5,9
20,2
10
13,9
611
3,2
32,8
8,0
696
4,4
23,1
15
12,5
548
2,6
35,7
6,6
573
3,1
26,0
20
11,0
485
2,1
38,7
5,2
452
2,0
28,8
Tw1/Tw2 = 70/50
o
C
V - airflow
PT - heat capacity
Tp1 - inlet air temperature
Tp2 - outlet air temperature
Tw1 - inlet water temperature
Tw2 - outlet water temperature
Qw - water flow rate
Δpw - water pressure drop
0
13,9
608
3,2
22,0
5
12,4
544
2,6
25,0
10
11,0
480
2,1
28,0
15
9,5
417
1,6
30,9
20
8,1
355
1,2
33,7
RECOMMENDED MOUNTING DISTANCE
AUTOMATIC ELEMENTS
LEO FS
S
M
RA
Room thermostat
RE
Room thermostat
with a weekly
programmer
TRs
1,5 A / 3 A five
step fan speed
regulator
TR / TRd
½” two-way valve
with actuator
SRQ2d
fan speed
controller with a
built-in room
thermostat
VNT20
Programmable
fan speed
controller with a
built-in room
thermostat
VNTLCD
Signal distributor
R10
Wall-mounted
temperature
sensor IP20
PT-1000
IP65
Wall-mounted
temperature
sensor IP65
Detailed information concerning mounting and electrical connections are available in the technical documentation of the device.
