La Nordica Glenda Wifi [12/32] Basic instructions
![La Nordica Glenda Wifi [12/32] Basic instructions](/views2/1335507/page12/bgc.png)
6
1
2
3
4
5
6
OFF
1
2
3
46
5
1 4
3
2
5
6
ENGLISH
General menu
Go back - exit
Parameter scrolling: next (2) ; previous (3)
Modify settings data: increase (4); decrease (5)
Conrm - access Menu
BasiC instruCtions
The following recommendations must be followed the rst times the
stove is ignited:
Faint smells may be produced due to the drying of the paints
and silicones used. Do not remain in the environment for long
periods.
Do not touch the surfaces as they could still be unstable.
Air the room well several times.
The hardening of the surfaces is terminated after several
heating processes.
This appliance must not be used to burn waste.
Before lighting the stove, the following points must be veried:
The hydraulic system must be completed in compliance with
the guidelines of the regulations and the manual.
The tank must be full of pellets
The combustion chamber must be clean
The burn pot must be completely free and clean
Check the hermetic closure of the re door and the ash drawer
Check that the power supply cable is connected correctly
The bipolar switch in the rear right part must be positioned on 1.
it is ForBiDDen to use the applianCe without the DiviDer anD/
or Glass proteCtion (see the FiGure to the siDe).
its removal jeoparDises the saFety oF the proDuCt anD
immeDiately voiDs the warranty perioD.
in the event oF wear or Deterioration ContaCt the assistanCe
serviCe to replaCe the part
(the replaCement is not CovereD By the proDuCt warranty
as it is a part suBjeCt to wear).
BURN POT DIVIDER
GLASS PROTECTION
USER MENU PELLET %
V1 AIR
RESET
SET CHRONO
ENABLE CHRONO
ENABLE PRG1
ENABLE PRG2
ENABLE PRG3
ENABLE PRG4
SETTINGS
SET CLOCK START PRG1
LANGUAGE
STOP PRG1
DISPLAY MONDAY PRG1...
STANDBY
...SUNDAY PRG1
DELTA T OFF SET PRG1
MENU
TECHNICIAN
(RESERVED TO THE
TECHNICIAN)
DELTA T ON
SAME STEPS FOR THE OTHER ONES
3 TIME SLOTS
12
