![La Nordica Viviana [25/32] Displays](/views2/1335495/page25/bg19.png)
ENGLISH
Displays
Display Reason solution
off
Stove o -
staRt
The start-up phase is in progress -
pellet feeDing
The feeding of the pellet during the ignition phase is in progress
ignition
The ignition phase is in progress -
BuRning
The start-up phase is in progress -
opeRant
The normal work phase is in progress -
MoDulation
The stove is modulating -
BuRn pot Cleaning
The automatic burn pot cleaning is in
progress.
The automatic burn pot cleaning (not in 1st power) is performed
at pre-established intervals of continued working.
final Cleaning
When the stove is switched-o, nal cleaning is in progress. The nal cleaning phase lasts about 10
minutes.
stanD-By
Stove o due to temperature reached
and in stand-by for re-ignition.
To deactivate the STAND-BY function see the specic chapter.
stanD By ext
Stove o due to an external
thermostat, waiting for re-ignition
To deactivate the STAND-BY function see the specic chapter.
Cooling stanD-By
A new ignition is attempted when
the stove has just been switched-o
When the stove switches o, it is necessary to wait for the
complete shutdown of the fumes motor before cleaning the burn
pot.
The stove can only be re-ignited when these operations have
been performed.
Cool. stDBy -
BlaCk out
The stove is cooling due to black out On completion of the cooling phase, it will re-ignite automatically.
low
Room thermostat set at minimum
value.
In this way the stove only works at 1st power independently
from the power set. To exit this function just raise the room
temperature using button 4 and then key 2.
Hot
Set room thermostat set at maximum
value.
The stove works at set start, without ever modulating. To escape
this function just lower the set temperature using key 4 and then
key 1.
seRviCe
When this message appears, contact the authorised technician for ordinary cleaning of the appliance.
If cleaning is not performed, the message will be displayed at every ignition but without interrupting
normal stove operation.
25
