![Hytera PD-785 [19/32] Radio set](/views2/1033627/page19/bg13.png)
14
Radio Set
You can optimize your radio performance by customizing related
parameters according to actual needs and your preferences.
Power Level
This option allows you to set TX power level. Alternatively, you
can change the power level by pressing the shortcut key for Adjust
Power Level in the home screen.
There are two levels available: High (indicated by ) and Low
(indicated by ). High power level enables you to communicate
with farther team members.
Note: Power level should be set for each channel
individually.
Squelch
This option allows you to select an appropriate squelch level.
Alternatively, you can change the squelch level by pressing
the shortcut key for Adjust Squelch Level in the home screen.
There are three levels available: Tight, Normal and Open. The
default squelch level is “Normal”, and is often used in low noise
environment.
And generally, “Tight” is used in high noise environment. It requires
stronger signal for the radio to unmute. However, if the squelch
level is set to Open, the speaker will keep unmuted irrespective of
the decoding conditions.
Scrambler /Encrypt
To set whether to enable the Scrambler/Encrypt feature.
Language
To set the language in which all interface information is displayed.
Backlight
To set the backlight parameters. There are three options available:
On, Off and Timer. The timer is programmed by your dealer, with
an available range of 5-60 seconds.
Brightness
To set the display brightness. You can raise or lower it using the
Up/Down key.
Keypad Lock
To set whether to enable this function. When “Enable” is selected,
you can use the Up/Down key to set the time range after which
the keypad will be locked. Available range: 5-60 seconds.
LED
To set whether to enable LED indication.
Tone
To set alert tones for your radio. You can set the following tones:
Radio Silent: to set whether the radio will give tone indication. If
Silent On is selected, all tone indication will be cancelled.
Talk Permit: to set whether the radio will give tone indication for
transmission. The following options are available: Disable (no
tone indication for transmission), Digital Only (tone indication for
transmission on digital channels only), Analog Only (tone indication
Menu Navigation
