АКСЕССУАРЫ ДЛЯ УСТАНОВКИ НА СТР. 212.
Installation accessories on page 212.
ВАРИАНТЫ УСТАНОВКИ Installation modes - NIKOLATESLA
NIKOLATESLA STANDARD ИСПОЛНЕНИЕ
РЕЖИМ ОТВОДА
NikolaTesla standard Duct-out mode
NIKOLATESLA STANDARD ИСПОЛНЕНИЕ ФИЛЬТРАЦИЯ
NikolaTesla standard Recycling modes
Thanks to the special
components provided by Elica,
installation is also possible in
kitchens whose base board is 60
mm high.
КОМПЛЕКТАЦИЯ
КОМПЛЕКТ NIKOLATESLA ВКЛЮЧАЕТ В СЕБЯ ВСЁ, ЧТО НЕОБХОДИМО (В СТАНДАРТНОЙ ВЕРСИИ) С ВОЗМОЖНОСТЬЮ УСТАНОВКИ КАК
В РЕЖИМЕ РЕЦИРКУЛЯЦИИ, ТАК И В РЕЖИМЕ ОТВОДА ВОЗДУХА. НИЖЕ ПРИВЕДЕНЫ ДОПУСТИМЫЕ ВАРИАНТЫ КОНФИГУРАЦИИ С
КОМПОНЕНТАМИ ИЗ КОМПЛЕКТА УСТАНОВКИ. В КАЧЕСТВЕ ДОПОЛНИТЕЛЬНЫХ АКСЕССУАРОВ ДОСТУПНЫ ОТВОДЫ И ТРУБЫ ДЛЯ ДРУГИХ
ВАРИАНТОВ УСТАНОВКИ.
IN THE BOX
NikolaTesla includes everything it needs (in the standard version) for being installed in both aspiration and filtering version.
Possible configurations, and related components included in the packaging, are mentioned below. For any other installation needs, bends and pipes are available as
accessories.
Cooking vapors are conveyed to
the outside by means of compact
pipes that pass into the free space
found under the bases, provided that
the base board height is at least
100 mm.
STREAM 37
75 CM
≥10 CM
60 CM
≥10 CM
60 CM
≥6 CM
60 CM
≥6 CM
805
+
2
830
+
2
490
+
2
515
+
2
5 mm
805
+
2
490
+
2
805
+
2
830
+
2
490
+
2
515
+
2
5 mm
805
+
2
490
+
2
NIKOLATESLA - ВАРИАНТЫ УСТАНОВКИ Installation modes
STANDARD
FILOTOP
830
515
4
210
РЕЖИМ ОТВОДА Duct-out
ФИЛЬТРАЦИЯ Recycling
БЛАГОДАРЯ
СПЕЦИАЛЬНЫМ
КОМПОНЕНТАМ ELICA,
УСТАНОВКА МОЖЕТ
БЫТЬ ПРОВЕДЕНА
ДАЖЕ В КУХНЯХ, ГДЕ
ВЫСОТА КАРКАСА 60
ММ.
ИСПАРЕНИЯ ОТ
ПРИГОТОВЛЕНИЯ
ПИЩИ ВЫВОДЯТСЯ ЗА
ПРЕДЕЛЫ ПОМЕЩЕНИЯ С
ПОМОЩЬЮ КОМПАКТНЫХ
ТРУБ, КОТОРЫЕ
РАЗМЕЩАЮТСЯ В
ЦОКОЛЕ ВЫСОТОЙ КАК
МИНИМУМ 100 ММ.
STREAM 36
60 CM
60 CM
≥6 CM
75 CM
≥6 CM
≥10 CM
“УМНАЯ СИСТЕМА” -
ТЕХНОЛОГИЯ, ПОЗВОЛЯЮЩАЯ
АВТОМАТИЧЕСКИ
ПОДСТРАИВАТЬ РЕЖИМ РАБОТЫ
ВЫТЯЖКИ ПОД РЕЖИМ РАБОТЫ
ВАРОЧНОЙ ПОВЕРХНОСТИ.
“Intelligent system” is the technology that
allows the fume aspiration device to self-
adjust according to the hob usage.
ДИЗАЙН NIKOLATESLA НАСТОЛЬКО УНИВЕРСАЛЕН, ЧТО СПОСОБЕН ВПИСАТЬСЯ В
ИНТЕРЬЕР ЛЮБОЙ КУХНИ. В СТАНДАРТНОЙ ВЕРСИИ ВЫТЯЖКИ, РАССЧИТАННОЙ НА
РАБОТУ В РЕЖИМЕ ФИЛЬТРАЦИИ, NIKOLATESLA ОСНАЩЕНА ВСЕМ НЕОБХОДИМЫМ
ДЛЯ УСТАНОВКИ, ВКЛЮЧАЯ ЭКСКЛЮЗИВНЫЙ ХРОМИРОВАННЫЙ ПРОФИЛЬ, КОТОРЫМ
ЗАВЕРШАЕТСЯ ВЫХОДНОЕ ОТВЕРСТИЕ В ЦОКОЛЕ КУХОННОГО МОДУЛЯ, НЕОБХОДИМЫЙ
ДЛЯ ВЫХОДА ВОЗДУХА. В ВАРИАНТЕ С ВЫВОДОМ ВОЗДУХА НАРУЖУ ТРУБЫ ЯВЛЯЮТСЯ
ДОПОЛНИТЕЛЬНЫМИ АКСЕССУАРАМИ, И КЛИЕНТ МОЖЕТ ВЫБРАТЬ ИДЕАЛЬНУЮ
КОНФИГУРАЦИЮ В СООТВЕТСТВИИ С ТРЕБОВАНИЯМИ И ОСОБЕННОСТЯМИ ДИЗАЙН-
ПРОЕКТА. NICOLATESLA МОЖНО УСТАНОВИТЬ НЕПОСРЕДСТВЕННО НА СТОЛЕШНИЦЕ
(СТАНДАРТ) ИЛИ РАЗМЕСТИТЬ В ПРОЕМЕ В 1 ММ., НЕ ВЫСТУПАЯ ЗА СТОЛЕШНИЦУ
(ВРОВЕНЬ).
NikolaTesla has been designed to fit into many different types of kitchens. In the standard filtering version,
NikolaTesla is equipped with every component needed for installation, including the exclusive chrome-
plated profile that finishes the air outlet hole at baseboard. In the aspiration version, pipes are supplied as
accessories and users can choose the best configuration\ solution, based on the architecture of their home.
It is possible to install NikolaTesla directly against the countertop (STANDARD) or inserted in a 1 mm slot,
blending in with the countertop. (FILOTOP).
