ENGLISH
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Only for hoods equipped with electronic control:
The 4th speed (intensive) is automatically lowered to 3rd speed after 5 minutes of operation to optimise energy
consumption; in hoods with voltage 120V/60Hz this function is not active and the 4th speed is indicated by
the letter b (Booster).
- If the hood is left on (lights and/or motor), after 10 hours in the absence of commands from the user, it will
automatically switch to OFF condition with all services switched off. In hoods with voltage 120V/60Hz this function
is not active.
- The Buzzer emits a “beep” each time that a command is set from the keyboard or remote control (optional).
- In the event of interruption of power during the hood, if you restore the hood in the OFF state, then the engine
must be reactivate manually.
Warning: Failure to install the screws or fixing device in accordance with these instructions may result
electrical hazards.
DESCRIPTION
The hood may be installed in the filtering or the ducting version. Filtering version (Fig. 1): The hood aspirates
the kitchen air saturated with fumes and odours, purifies it through the grease filters and charcoal filters and returns
clean air into the room. For constant efficiency, the charcoal filters must be replaced periodically. The charcoal
filters are not supplied. Ducting version (Fig. 2): The hood aspirates the kitchen air saturated with fumes and
odours, passes it through the grease filters and expels it to the outside through an outlet pipe. With this version
the charcoal filters are not required.
Decide from the outset on the type of installation (filtering or ducting). For greater efficiency, we recommend
you install the hood in the ducting version (if possible).
The 2-motor version hood is only available for ducting version installation.
INSTALLATION
ATTENTION: 2 people are required for proper installation; the unit should be installed by a qualified
operator.
INSTALLATION IN DUCTING VERSION:
1. Before fixing, the disposal duct for air evacuation to the outside must be installed. Use an disposal duct
with: – minimum indispensable length; – minimum possible bends (maximum angle of bend: 90°); – certified material
(according to the State); – an as smooth as possible inside. It is also advisable to avoid any drastic changes
in pipe cross-section. We recommend using a 150 mm diameter pipe for model shown in Figure 3, and a 200 mm
diameter pipe for the model shown in Figure 4. For air evacuation to the outside, follow all the other instructions
given on the “Warnings” sheet.
2. If you have purchased the 2-motor version (model shown in Fig. 4), you must fit the plastic flange using
4 screws (3,9 x 9,5 mm).
3. Prepare a suitable power supply. For the electrical connection, follow all the other instructions on the
“Warnings” sheet.
4. Check to see the grease filters have been removed; if necessary, remove these by moving the catch
(B) and turning these outwards (Fig. 5).
5. Make a hole for housing the appliance (Fig.6) in the bottom of the wall unit. The bottom of the wall unit
must have a thickness of between 15 and 20 mm.
6. Take 4 retention screws from the accessories bag (4,2 x 15 mm). Fit the appliance in the hole made
on the wall unit, first positioning the rear part, so the flap on the back rests on the wall unit; next, slightly slide
the appliance back, towards the wall (Fig. 7).
Without leaving the appliance, secure this to the wall unit by means of the 4 screws (Fig. 8).
7. Proceed with final fitting, using the 4 screws (4,2 x 15 mm); See Fig. 9.
8. Connect the disposal duct to the air evacuation pipe of the hood. Use a flexible pipe and lock it to the
air evacuation pipe of the hood with a metal hose clamp (pipe and clamp are not provided). Make the electrical
connections.
9. Refit the grease filters.
INSTALLATION IN FILTERING VERSION:
Proceed with installation, making reference to the instructions for the extraction version (see points 3, 4, 5,
6, 7), and then follow the instructions below.
Connect the hose to the hood air outlet so the air is conveyed to the top of the wall unit; secure the hose
with a metal clamp (hose and clamp are not provided). Make power connections.
Check whether the charcoal filters have already been fitted. If necessary, proceed to fit these as follows:
rest the charcoal filter on the motor unit by making the pins coincide; turn the charcoal filter until this is fast
(Fig. 10).
Refit the grease filters.
