8
Water connection
Water connectionWater connection
Water connection
CAUTION:
CAUTION:CAUTION:
CAUTION:
• The Installation of the water supply must conform to the local laws and regulations.
• Use the new supplied hose set to connect the appliance to the water supply. Do not reuse old or used
connection sets.
• If the water pipe is new or long time not used, ensure before connecting to the water system, that the water
is clear and free from contamination.
Notes
Notes Notes
Notes on inlet hose safety system
on inlet hose safety systemon inlet hose safety system
on inlet hose safety system
The safety system consists of a double-walled inlet hose. This system guarantees to cut off the water supply
when leakage of the inner hose. Switching off the water supply leads over an electronic contact.
Connect the water
Connect the water Connect the water
Connect the water inlet
inletinlet
inlet
hose (cold water connection)
hose (cold water connection)hose (cold water connection)
hose (cold water connection)
NOTE
NOTENOTE
NOTE:
::
:
The water pressure must be between 0.04 and 1 MPa. With higher pressure: use a pressure regulator.
• Connect the water inlet hose to a water thread with ¾“. Screw the hose firmly in the direction
of the screw thread; pay attention for a tight fit.
• Connect the other end of the inlet hose to the inlet valve on the appliance back; pay attention
for a tight fit too.
Hot water supply
Hot water supplyHot water supply
Hot water supply
The dishwasher can be supplied with a water temperature of not more than 60°C. Supplying the appliance
with hot water, the rinse running time is shortened but the cleaning effect can be slightly reduced. The con-
nection to the hot water valve must be done in the same manner as described for the cold water connection.
Connect the water drain hose
Connect the water drain hoseConnect the water drain hose
Connect the water drain hose
NOTE
NOTENOTE
NOTE:
::
:
The drain hose has a length of approx. 1.5 m and can extend with a suitable hose and connecting piece to a
length of max. 4 m.
CAUTION
CAUTIONCAUTION
CAUTION:
::
:
In order to prevent backflow of contaminated water, the free end of the hose must not come under the water
level of the drain.
• Connect the drain hose to a drain pipe with a minimum diameter of Ø 40 mm;
alternatively the drain hose can be fixed directly to the sink.
• Always make sure that the hose is not bent or squeezed.
• It is allowed to install the hose maximal up to a height of 1000 mm above the
rinsing floor.
• Secure the drain hose securely to avoid a change in position and with it a
water leakage.
