Lincat BM3AFL [5/8] Operating instructions
![Lincat BM6AFL [5/8] Operating instructions](/views2/1337398/page5/bg5.png)
IS 221 ECN3607 Page 5 of 8
Install this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material. Minimum
distances A 100mm B 500mm – see Fig 1.
This appliance is fitted with adjustable feet for levelling.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
When fitting countertop appliances to SLS stands, the feet should be located into
the corresponding holes in the base appliances. When fitting onto Ovens, HC
Pedestals or similar closed bases, the feet may be removed.
Power ratings
Model
Power (kW)
Dry Heat
BM3
0.50
BA3, BS3
0.50
BM4
0.75
BA4, BS4
0.75
BM6
0.75
BM7
1.00
BA7, BS7
1.00
Wet Well Heat
BM3W
1.00
BS3W
1.00
BM4W
1.00
BS4W
1.00
BM6W
2.00
BM7W
2.00
BS7W
2.00
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
Bains Marie are intended to maintain food temperature only and are not designed
as a cooker.
Dry Heat Models
Do not fill Dry Heat Models with water.
Switch on the power supply – the green neon illuminates.
