IS 400 ECN 3607 Page 4 of 11

CHECK LIST OF ENCLOSURES

Warranty card

Instructions manual

Baskets

Lid knob

Drain tube

Element lifting hook

Oil drainage bucket (J models)

Sieve

Sieve (J models)

Feet (J models)

Stability Bracket (J6, J9)

INSTALLATION AND COMMISSIONING

This appliance must be earthed.

An equipotential bonding terminal is provided to allow cross bonding with other

equipment.

If replacing the plug connect the terminals as follows:

Green and Yellow wire Earth E

Blue wire Neutral N

Brown wire Live L

Means of isolation with at least 3mm contact separation in all poles must be

incorporated into the fixed wiring of this appliance.

The fixed wiring insulation must be protected by insulated sleeving having a

temperature rating of at least 60 Deg C.

Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary

polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)

Install this appliance on a level surface ensuring all vents are unobstructed. Any

partitions, walls or furniture must be of non-combustible material. Minimum

distances A 100mm B 1000mm – see Fig 1.

Operate this appliance beneath an extraction canopy.

Models up to 3kW are fitted with a plug and lead. Models over 3kW must be

installed by a qualified electrician

It is essential that the stability kit provided is used with J6 and J9 fryers. Bolt the

base plate to the floor, attach the stability bracket and push the fryer into position,
