IS590 ECN 3846 Page 4 of 12

INSTALLATION AND COMMISSIONING

This appliance must be earthed.

If replacing the plug connect the terminals as follows:

Green and Yellow wire Earth E

Blue wire Neutral N

Brown wire Live L

Means of isolation with at least 3mm contact separation in all poles must be

incorporated into the fixed wiring of EB4FX, EB6FX and EB6TFX appliances.

Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary

polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)

Install this appliance on a level surface ensuring all vents are unobstructed.

Only install this unit in locations where it can be overseen by trained personnel.

Inlet water pressure should be between 2 and 6 bar. (0.2MPa to 0.6MPa)

Ambient air temperature shall be between 5 and 30 deg C

Electrical supply

The EB3FX series are supplied with a 13 amp plug to BS1363.

The EB4FX is supplied with a bulkhead cable connector. Connect a 2.5mm

3 core

cable.

The EB6FX and EB6TFX are supplied with a bulkhead cable connector. Connect a

4mm

3 core cable.

Means of isolation with at least 3mm contact separation in all poles must be

incorporated into the fixed wiring of these appliances.

Water supply and waste connection (All)

Connect the supplied white water inlet hose to the inlet connection point on the

base of the boiler and the other end to the mains supply via an accessible isolating

tap with a ¾” BSP thread.

Use the hose set supplied with the appliance - any previous hose set is not to be re-

used.

Ensure the metal overflow pipe protrudes through the metal base of the boiler.

Potable water. If solid particles are known to be in the supply, add an extra inline

filter or strainer
