 Loosen the retaining nut at the rear of the burner.

 Loosen the retaining nut at the injector end of the burner.

 Remove the burner retainer bracket and the heat shield mounting screws.

 Lift the burner clear of the assembly.

 Refitting is the reverse of the above.

3.3 SPARES LIST

The following components are listed with the Lincat reference number followed by a brief description.

VA11 Multi function valve. *

TC34 Thermocouple.

BU87 Griddle burner.

JE35 GS7/N Burner injector – natural gas – stamp code: 160

JE141 GS7/P Burner injector – propane gas – stamp code: 75

JE68 GS4/N Burner injector – natural gas – stamp code: 210

JE67 GS4/P Burner injector – propane gas – stamp code: 100

PG10 Governor – Natural gas / Propane

KN184 Control knob

Note: When ordering a replacement valve the unit and gas type must be specified as the valves are

factory pre-set for the low rate settings.
