9
BLT373
• Please refer carefully to the system diagram before installing your BLT373.
Incorrect wiring method may cause damage to BLT373, your car audio system
or even your vehicle.
• We strongly recommend that BLT373 is only installed by those fully familiar
with your vehicle’s electrical system, please consult with the supply retailer if
any doubt.
CAUTION
!
3. INSTALLATION
Figure 3: Fix the BLT373 to the car sun visor
Figure 4: Fix the BLT373 to the dashboard
Bluetooth
®
Audio/Mobile-phone Transceiver unit
Bluetooth
®
Audio/Mobile-phone Transceiver unit
