Cleaning the Satellite (Daily)
CLEANING INSTRUCTIONS CI3
GEM SATELLITE, CLEANING INSTRUCTIONS 062817A
WARNING: DO NOT immerse the satellite in water or any other liquid. Do not place the satellite in a dishwasher.
Placing the satellite in a dishwasher will void the warranty.
Cleaning the Liner
1 Prepare a mild solution of detergent and warm water.
Remove the satellite from the brewer and remove the
lid. Rinse.
2 Wash - Wipe the exterior surfaces of the satellite
with a sponge soaked with the detergent solution
to remove spills and debris. Fill the liner with the
detergent solution. Take a sponge brush and scrub
out the stainless steel liner and the lid.
3 Rinse - Rinse with clean, warm water.
4 Sanitize - Sanitize the interior of the satellite and
the lid, using a commercial sanitizer suitable for
food grade applications. Sanitize according to the
directions on the package.
5 Disassemble the faucet - Unscrew the handle/
bonnet assembly from the top of the faucet and
remove it. Inspect the seat cup for wear. Replace the
seat cup if it is damaged.
Disassemble the sight gauge (some versions).
Remove the cap and unscrew the guard, as shown,
to disassemble the gauge. Remove the glass tube.
Inspect it for cracks or chips. If broken, replace the
glass with a new one.
6 Air Dry - Turn the satellite and lid upside down and
allow to air dry.
Cleaning the Faucet Parts and Site Gauge
7 Wash - Wash all faucet and gauge glass parts with
the detergent solution. Clean the inside of the gauge
glass with a gauge brush soaked with detergent
solution.
8 Rinse - Thoroughly rinse all parts with clean, warm
water.
9 Sanitize - After rinsing, place all faucet and gauge
parts in a sink to be sanitized. Immerse them in
a commercial sanitizer suitable for food grade
applications. Sanitize according to the directions on
the package.
continued...
Seat cup
Handle
Bonnet
Cap
Washer
Washer
Glass tube
Site glass guard
WASH
SANITIZE
RINSE
