Mounting Screw
Installing CM-HS1
It is important that the module is installed with the internal microphone
facing towards the user.
Use the Visor Clip to fix the module to the car sun visor, and route the
main cable properly.
(
shown in Fig. 2
)
Use the given mounting screws to tighten the module
(
shown in Fig. 1
)
to the Visor Clip if necessary. If installing the module anywhere else, care
must be taken in order not to damage the connector of the unit.
(
shown
in Fig. 3
)
Check that the location of the microphone
is adequate to pick-up the car
driver voice.
Installation
Fig. 1
6 BLT433
English
