Commax CMD-104VU [11/14] Specification

6. Specification

Building Distributor 5 Wire (Polarized cable) , CCTV 4 Wire (Polarized cable)

(RJ45 CAT5e Patch Cable)

Power DC 14V / 4A

1. Designated CCTV  CMD-104VU LINE1,2,3,4

2. CMD-104VU OUT(Output)  CMD-104VU IN (Expansion)

3. CMD-104VU OUT (Output)  Building Distributor(CMD-101BU)

1. CCTV  CMD-104VU  CMD-101BUCMD-404FU

 House unit Videophone : Max. 300m

2. CCTV  CMD-104VU : Max. 50m

(Max. two CCTV Selector can be installed)

Model

Spec

CMD-104VU (CCTV video selector)

Transmission type

Distance

Cabling step
