3-1. The name of parts
3. Parts
4
NO. Description NO. Description
1 Camera
2 Night Lamp
3 Speaker
4 OLED Display
5 RFID card receiver
Name Searching button /
Menu Page Button
Up & Down scroll button/
Program Button
8 Call Button
9 Number button
10 Cancel Button
11 C-MIC
12 Electric Key Button
13 Camera angle
14 Line connecting button
15 Reset Button
16 Circuit Connect Switch
