10
9. Specifications and Features
Rated Voltage AC100-240V~, 50/60Hz
Power Consumption Operating : 15W
Wiring 4 wires with door camera (Polarity),
4 wires with an Interphone (Polarity)
Screen Size Color 5" (12.7cm) TFT LCD
Communication Simultaneous communication
From a door camera: Electric chime
From an interphone: Beep sound
Time to display the screen 60 ± 10sec
Distance from camera 28m(Ф0.5) / 50m(Ф0.65) / 70m(Ф0.8)
Operating Temperature 0 ~ +40℃ (32°F ~ 104°F)
Weight 2kg
Dimension 259(W)× 158(H)× 52(D)mm
CDV-50P
CDV-50N
Call Sound
Reference : Design and functions of the product are a subject of constant
development as a pursuit of quality improvement
