Commax CDS-2AG [2/22] Things to be aware before installation

1

Contents

1. Things to be aware before installation

1. Things to be aware before installation ..........................................................1

2. Important Safeguards .....................................................................................2

3. Parts . . ...........................................................................................................4

4. Household unit call..........................................................................................7

5. To call a lobby phone .....................................................................................8

6. To page a household unit by Registered LP (License Plate) number .........8

13. To set the time ............................................................................................12

14. Registration (Please review thoroughly)....................................................12

15. Built-in Program (Security Station).............................................................16

16. System Diagram .........................................................................................18

17. Wiring .........................................................................................................19

18. Other information .......................................................................................20

19. Specification and Feature...........................................................................20

󰢟CDS-2AG is to be connected with a lobby phone at the public entrance via 4 common

wires with 1 channel / 2-wire voice communication, “Balanced Type”.

󰢟CDS-2AG is expandable up to 4 stations by allocating an ID to each device.
