Power On:

For 02703, 02705:

Put 2 AAA size batteries into the remote sensor according

to the “+””-” indicator in the compartment, it will be in full

display for 2 seconds and display the current temperature

and humidity. Then you can see the blink of the channel

numbers, press the backside “CH” button to choose the

required channel number, after confirmed the channel

number for 8 seconds, the indicator light will flash one

time. It means that it had begin to send the signal of tem-

perature and humidity.Once the indicate light of the

remote sensor flash one time, it means that it sends the

data of the temperature and humidity, the main station

will display the temperature (and humidity) of the remote

sensor after receiving the signals successfully. The number

inside the left circle is the channel number of the remote

sensor.

For 02700:

• The weather station automatically starts receiving trans-

mission from Outdoor Thermo Sensor for outdoor tempera-

ture after new batteries are inserted.

• The sensor will automatically transmit temperature to the

weather station after batteries inserted. Batteries compart-

ment of thermo sensor is locating behind the back cover.

• For having more than one external transmitter (Maximum

3), select the Channel, CH1, CH2 or CH3 to ensure each

sensor is transmitting difference channel inserting batteries.

The channel select switch is at the back of the thermo sen-

sor.

• Press "TX" button on the thermo sensor unit transmit tem-

perature to the weather station manually .The weather sta-

tion gives a "beep" sound if it received the temperature.
