![RST RST02875 Инструкция по эксплуатации онлайн [2/10] 284914](/views2/1343115/page2/bg2.png)
2
H. Outdoor remote sensor indicator
Indicates the current outdoor remote sensor signal received. It can display up to 3 different remote sensors which is
placed in 3 different places and within 75 meter distance from the main unit.
I. Auto scroll indicator
The animated rolling arrow icon is shown to indicate the auto scroll of 3 different remote channel.
J. Outdoor maximum/minimum indicator
Indicates the maximum/minimum outdoor temperature is displayed
K. Remote sensor battery low indicator
Appears when the batteries of the remote sensor are running dry and the temperature measured by this sensor is no longer
reliable. The user must change the batteries at once.
DESCRIPTION OF BUTTONS
1. [ LIGHT/SNOOZE] is contactless key sensing by an IR motion sensor
IR motion sensor is placed between the crystal and LCD display to detect a motion up to 3 inches distance. When triggered,
activate backlight for 16 seconds (24 seconds if with adaptor) or stop alarm temperately for 5 minutes when alarm sounds;
2. [ CLOCK ]
- Press once to toggle for clock, calendar & alarm display mode.
- Press and hold 2 seconds to enter the setting of the display mode – Clock/Calendar/Alarm
3. [
]
- Press once to increase the setting in CLOCK, CALENDAR or ALARM setting mode
- Press and hold 2 seconds to manually activate or deactivate the radio controlled function
4. [
]
- Press once to decrease the setting in CLOCK, CALENDAR or ALARM setting mode
- Press once to arm or disarm the daily alarm under alarm display mode
5. [ CHANNEL ]
- Select among channel 1, 2, 3 or to enter auto scroll mode.
- Press and hold 2 seconds to activate or deactivate the sensor searching mode
6. [ MEMORY ]
- Toggle for max or min temperature memory reading for both IN & OUT thermometers
- Press and hold 2s to clear individual memory when the Max or Min temperatures are displayed
7. [ UNIT ]
- Toggle for setting temperature display unit °C or °F
- Press & hold 2s to set the crystal weather icon illumination cycle
8. [ RESET ]
- Press once to trigger system reset and restore all setting to factory default
Slide switch [BACKLIGHT] to select the backlight mode
GETTING STARTED
This Weather Station was designed for easy set up. For best operation, the following steps are required to be done in the
proper sequence.
1. INSERT BATTERIES FOR MAIN UNIT BEFORE DOING SO FOR THE SENSOR UNITS.
2. RECEIVING UNIT CANNOT BE PROGRAMMED MANUALLY UNTIL THE WIRELESS REMOTE SENSOR UNIT
REGISTRATION PROCEDURE HAS BEEN COMPLETED.
3. POSITION THE REMOTE UNIT AND MAIN UNIT WITHIN EFFECTIVE TRANSMISSION RANGE, WHICH, IN
USUAL CIRCUMSTANCES, IS 250 FEET.
Although the remote unit is weather resistant, it should be placed away from direct sunlight, rain or snow.
BATTERY INSTALLATION FOR MAIN UNIT
1. Turn the metal nut anti-clockwise on the bottom of the unit to open and release the battery compartment;
2. Insert 4 AA size 1.5V alkaline battery as indicate by the polarity;
3. Push the battery compartment back, turn the metal nut clockwise to lock;
Note: Replace the batteries when the low battery indicator appears on the top-right corner of the LCD.
Power Supply
Slide switch position Battery Only Battery & Adapter Adapter only
Auto Wave hand in front of the IR Wave hand in front of the IR sensor to activate backlight
sensor to activate backlight for 24 seconds
for 16 seconds
OFF Disable the backlight function
ON Wave hand in front of the IR Backlight always on
sensor to activate backlight
for 16 seconds
