Open the bottom battery cover of main station, install 3 PCS AA batteries into the battery compartment,

according to “+”, “-” indicator. The LCD will be in full display for 2 seconds, “--.-” will blink in the place of outdoor

temperature. It means that main unit was searching signal of remote sensor, the longest searching time is 2 min-

utes. Install 2 PCS AAA batteries into the battery compartment of remote sensor according to “+”, “-” indicator.

it will be in full display for 2 seconds and display the current temperature. Then you can see the blink of the chan-

nel numbers, press the backside “CH” button to choose the required channel number, after confirmed the

channel number for 8 seconds, the indicator light will flash one time. It means that it begins to send the signal of

temperature , at the same time, the outdoor temperature on the main unit can receive the signal of remote sen-

sor and show the current temperature in the display zone. Once the indicative light of the remote sensor flash

one time, it means that it transfers the data of the temperature, the main unit will display the temperature of the

remote sensor after receiving the signals successfully. The number inside the left circle is the channel number of

the remote sensor. After 3 minutes, the main unit will turn to radio controlled receiving for 10 minutes. If the signals

are not received, the date can also be set manually. When it does receive the signal, it will change the time

automatically into the received time.

Press and hold “light m demo +” button for 3 seconds, it will enter into DEMO MODE and it will demonstrate dif-

ferent backlight colors, time, temperature and all the functions on the main unit. In the DEMO MODE, press “light

m demo +” once, it will exit the DEMO MODE.

RST 02888 31

POWER ON

DEMO MODE
