Fractal Design

Node 304 computer case

The Node 304 is a compact computer case with a unique and versatile modular interior that

allows you to adapt it according to your needs and components. Whether you want a cool

le server, a quiet home theater PC or a powerful gaming system, the choice is yours.

The Node 304 comes complete with three hydraulic bearing fans, with the option of using

tower CPU coolers or a water cooling system. All air intakes are equipped with easy-to-

clean air lters, which reduce dust from getting into your system. The strategic placement of

the hard drives directly facing two front-mounted Silent Series R2 fans ensures that all your

components remain at optimal cool temperatures. Unused hard drive disk brackets can be

easily removed to make room for long graphic cards, increased airow, or additional space

for organizing cables.

The Node 304 carries on the Fractal Design legacy of minimalistic and sleek Scandinavian

design combined with maximum functionality.

Installation / instructions

To take full advantage of the improved features and benets of the Node 304 computer

case, the following information and instructions are provided.

System installation

The following steps are recommended for mounting components in a Node 304:

1. Remove the three hard drive mounting brackets.

2. Mount the motherboard using the provided motherboard standoffs and screws.

3. Install the ATX power supply using the screws provided (see detailed description be-

low).

4. If desired, mount a graphics card (see detailed description below).

5. Mount the hard drive(s) to the white bracket(s) using the provided screws.

6. Mount the hard drive brackets(s) back into the case.

7. Connect the power supply and motherboard cables to the components.

8. Connect the power supply extension cable to the power supply.

Installing hard drives

Installing hard drives in the Node 304 is similar to standard computer cases:

1. Dismount the hard drive brackets from the case by removing the screw located in the

front with a Phillips screwdriver and the two thumb screws in the back.

2. Mount the hard drives with their connectors facing to the rear of the case, using the

screws provided in the accessory box.

3. Put the bracket back into the case and secure it before plugging in the connectors;

unused hard drive brackets can be left out for increased airow.

Installing the power supply

The power supply is easiest to install after the motherboard has been installed:

1. Slide the PSU into the case, with the power supply fan facing downwards.

2. Secure the power supply by fastening it with the three screws provided in the acces-

sory box.

3. Plug in the pre-mounted extension cable in your power supply.

4. Lastly, plug in the cable that came with the power supply at the back of the case and

turn on your power supply.
