Basic Operations

English

10 CX501E

● Adjusting the subwoofer output

volume

You can adjust the volume output from the unit’s

subwoofer output terminal.

This adjustment can be performed only when

the “REAR/S-W” is set to “S-WOOFER”

(page 22).

2-1. Select “S-W VOL”.

3-1. Turn the [ROTARY] knob to increase or

decrease the subwoofer volume.

∗ The factory default setting is “0”.

(Adjustment range: +6 to –6)

● Setting the PHASE

This set can be performed only when the

“REAR/S-W” is set to “S-WOOFER” (page 22).

2-1. Select “PHASE”.

3-1. Turn the [ROTARY] knob to select as

following order:

“NORMAL” ↔ “REVERSE”

∗ The factory default setting is “NORMAL”.

● Adjusting the HPF

2-1. Select “HPF”.

3-1. Turn the [ROTARY] knob to select as

following order:

“THROUGH” ↔ “60” ↔ “90” ↔ “120”

∗ The factory default setting is “THROUGH”.

Note:

• During SOUND adjustment mode, if no operation

is performed for more than 10 seconds, this

mode can be cancelled and return to previous

mode.

CT (Clock Time) function

The CT function receives CT data sent from an

“Radio Data System” station and displays the

time.

∗ If a CT data is not being received, “CT– –:– –”

appears in the display.

Note:

• CT data is not transmitted in some countries and

by some broadcast stations. Also, in some areas,

the CT may not display accurately.
