Basic Operations
English
9 CX501E
When “CUSTOM” is set:
3-1. Press the [ROTARY] knob.
3-2. Press the [x] or [v] button to select the
“BASS”/“MID”/“TREBLE” mode to adjust.
3-3. If you want to set the flat, press the
[ROTARY
] knob to return to the “CUSTOM”
mode, then press and hold the
[ROTARY
]
knob (1 sec.), bass/mid/treble
characteristics become flat.
When “EXCITE/IMPACT/B-BOOST” is set:
3-2. Press the [ROTARY] knob.
3-3. Turn the [ROTARY] knob to adjust the
setting in the range of
–3 to +3.
∗ The factory default setting is “0”.
3-4. Press the [ROTARY] knob to return to the
previous mode.
● Adjusting the BASS/MID/TREBLE
This adjustment can be performed only when
the BEAT EQ is set to “CUSTOM”.
Note:
• While connected with the external amplifiers,
please do not set the “BASS”/“MID”/“TREBLE”
in the maximum level. Otherwise the speakers
may be damaged.
3-2. Press the [ROTARY] knob.
3-3. Press the [x] or [v] button to select as
following order:
“BASS<G>” ↔ “BASS<F>” ↔ “BASS<Q>”
“MID<G>” ↔ “MID<F>” ↔ “MID<Q>”
“TREBLE<G>” ↔ “TREBLE<F>” ↔
“TREBLE<Q>”
∗ The factory default setting is “BASS<G>”.
3-4. Turn the [ROTARY] knob to select the
setting.
BASS<G>:The factory default setting is “0”.
(Adjustment range: +7 to –7)
BASS<F>:
The factory default setting is “
50
”
.
(Adjustment range: 50/100/200)
BASS<Q>:The factory default setting is “1”.
(Adjustment range: 0.7/1/1.4/2)
MID<G> : The factory default setting is “0”.
(Adjustment range: +7 to
–7)
MID<F> :
The factory default setting is “
500
”.
(Adjustment range: 500/1K/2K)
MID<Q> :
The factory default setting is
“1”
.
(Adjustment range: 0.7/1/1.4/2)
TREBLE<G>
:
The factory default setting is
“
0
”
.
(Adjustment range: +7 to –7)
TREBLE<F>:
The factory default setting is
“
10K
”.
(Adjustment range: 5K/10K/15K)
TREBLE<Q>
:
The factory default setting is
“
1
”
.
(Adjustment range: 0.7/1/1.4/2)
3-5. Press the [ROTARY] knob to return to the
previous mode.
Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low frequencies like the normal sound
adjustment function, but emphasizes the deep
bass frequencies to provide you with a dynamic
sound.
∗ The factory default setting is “OFF” (off).
2-1. Select “M-B EX”.
3-1. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Turn the [ROTARY] knob to adjust the
balance of the right and left speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: RIGHT12 to
LEFT12 (right 12 to left 12))
● Adjusting the fader
2-1. Select “FADER”.
3-1. Turn the [ROTARY] knob to adjust the
balance of the rear and front speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: FRONT12 to
REAR12 (front 12 to rear 12))
● Adjusting the subwoofer
You can set the low pass filter of subwoofer.
This adjustment can be performed only when
the “REAR/S-W” is set to “S-WOOFER”
(page 22).
2-1. Select “LPF”.
3-1. Turn the [ROTARY] knob to select as
following order:
“THROUGH” ↔ “60” ↔ “90” ↔ “120”
∗ The factory default setting is “THROUGH”.
CX501E_EN.book Page 9 Thursday, November 11, 2010 1:16 PM
