111
E-80-R
No. Description Qty
1 Console 1
2 Main frame 1
3 Screw M8xP1.25x12Lx5t 3
4 Pulley 1
5 Axle 1
6 Bushing 1
7 Right crank 1
8 Left crank 1
9 Idler 1
10 Idler wheeel 1
11 Nut M8 1
12 Flat washer Ø8.5xØ25x1t 1
13 Curve washer Ø10.5xØ15x0.3t 1
14 Flat washer Ø6xØ12x1t 1
15 Screw M6xP1.0x12L 1
16 Spring ODØ16xØ2.0x20T 1
17 EMS Flywheel Compl. 1
18 Screw M6xP1.0x16L 4
19 Spring washer Ø6*1.5T 4
20 Flat washer Ø6xØ13x1t 4
21 Screw M10x50L 2
22 Screw M8xP1.0x20L 2
23 Nut M17 1
24 Flat washer Ø17.5xØ25x1t 1
25 Left chain cover 1
26 Right chain cover 1
27 Shaft of chain cover 2
28 Rear cover (L) 1
29 Rear cover (R) 1
30 Top cover 1
31 Cover of bottom tube 1
32 Cap of crank(outter) 2
33 Cap of crank(inner) 2
34 Screw M5x12L 4
35 Screw M5x16 9
36 Screw M4x10L 3
37 Screw M4x50L 1
38 Cable (lower) 1
39 Control board 1
40 Connection wire (flywheel &
control board)
1
41 Connection wire 1
42 Sensor wire 1
43 DC wire 1
44 Screw M4xP1.5*16L 2
45 Sensor base 1
46 Flat washer Ø5xØ10x1t 2
47 Bearing 6203 (RS) 2
48 Drive belt 1
49 Screw M8xP1.25x55L 4
50 Flat washer Ø8xØ16x2t 4
51 Nut M8 4
52 Bushing 4
53 Adjusting cushion 1
54 Isolated column 4
55 Handlebar post 1
56 Cable (Upper) 1
57 Connection wire 1
58 Foam grip 2
59 End cap 2
