Item No. Description Qty

1 Main Frame Assembly 1

2 Link Assembly 1

3 Left Upright 1

4 Right Upright 1

5 Weight Horn Assembly 4

6 Back Pad 1

7 Rack Out Plate 2

8 Flanged Spacer 12

9 End Cap Domed 4

10 Rubber Foot 5

11 Plug RT50*100 4

12 Weight Horn Rubber Donut 4

13 Outside Plate 2

14 Socket Head Cap Screw M10*35 4

15 Button Head Cap Screw M10*30 8

16 Button Head Cap Screw M10*75 2

17 Button Head Cap Screw M10*80 8

18 Button Head Cap Screw M12*70 6

19 Nylon Lock Nut M10 8

20 Nylon Lock Nut M12 6

21 Flat Washer Φ11*Φ20*2 26

22 Hex Key S=6 1
