Start-up and use

! The position of the corresponding gas burner is shown on every knob.

Gas burners

Each burner can be adjusted to one of the following settings using the

corresponding control knob:

● Off

Maximum

Minimum

To light one of the burners, hold a lit match or lighter near the burner and, at

the same time, press down and turn the corresponding knob anti-clockwise

to the maximum setting.

Since the burner is tted with a safety device, the knob should be pressed

for approximately 2-3 seconds to allow the automatic device keeping the

ame alight to heat up.

Some models are equipped with an ignition button incorporated into the control

knob. If this is the case, the ignitor is present, but not the button.

To light a burner, simply press the corresponding knob all the way in and

then turn it in the counter-clockwise direction to the “High” setting, keeping

it pressed in until the burner lights.

! If a ame is accidentally extinguished, turn off the control knob and wait for

at least 1 minute before trying to relight it.

To switch off the burner, turn the knob in a clockwise direction until it stops

(when reaches the “●” position).

Practical advice on using the burners

To ensure the burners operate efciently:

• Use appropriate cookware for each burner (see table) so that the ames

do not extend beyond the bottom of the cookware.

• Always use cookware with a at base and a cover.

• When the contents of the pan reach boiling point, turn the knob to minimum.

Rapid (R)

Reduced Rapid (RR)

Semi Rapid (S)

Auxiliary (A)

Mini WOK (MW)

Ø Cookware Diameter (cm)

24 - 26

16 - 20

10 - 14

24 - 26

Burner

To identify the type of burner, refer to the designs in the section entitled, “Burner

and Nozzle Specications”.

• For maximum stability, always make sure that the pan supports are

correctly tted and that each pan is placed centrally over the burner.

• Pan handles should be positioned in line with one of the support bars on

the pan support grid.

• Pan handle should be positioned so not to protrude beyond the front edge

of the hob.

The more variable aspect in terms of pan

stability can often be the pan itself, (or

the positioning of that pan during use).

Well balanced pans, with at bases that

are placed centrally over the burner, with

the pan handles aligned with one of the

support ngers obviously offer the greatest stability.

Precautions and tips

! This appliance has been designed and manufactured in compliance with

international safety standards. The following warnings are provided for safety

reasons and must be read carefully.

General safety

• This is a class 3 built-in appliance.

• Gas appliances require regular air exchange to maintain efcient

operation. When installing the hob, follow the instructions provided

in the paragraph on “Positioning” the appliance.

• These instructions are only valid for the countries whose symbols

appear in the manual and on the serial number plate.

• The appliance was designed for domestic use inside the home and is not

intended for commercial or industrial use.

• The appliance must not be installed outdoors, even in covered areas. It is

extremely dangerous to leave the appliance exposed to rain and storms.

• Do not touch the appliance with bare feet or with wet or damp hands and

feet.

• The appliance must be used by adults only for the preparation of food,

in accordance with the instructions outlined in this booklet. Any other

use of the appliance (e.g. for heating the room) constitutes improper

use and is dangerous. The manufacturer may not be held liable for

any damage resulting from improper, incorrect and unreasonable

use of the appliance.

• The openings used for ventilation and dispersion of heat must never be

covered.

• Always make sure the knobs are in the “●”/“○” position when the appliance

is not in use.

• When unplugging the appliance always pull the plug from the mains socket,

do not pull on the cable.

• Never carry out any cleaning or maintenance work without having detached

the plug from the mains.

• In case of malfunction, under no circumstances should you attempt to repair

the appliance yourself. Repairs carried out by inexperienced persons may

cause injury or further malfunctioning of the appliance. Contact a Service

Centre (see Assistance).

• Do not close the glass cover (if present) when the gas burners or electric

hotplates are still hot.

• The appliance should not be operated by people (including children)

with reduced physical, sensory or mental capacities, by inexperienced

individuals or by anyone who is not familiar with the product. These

individuals should, at the very least, be supervised by someone who

assumes responsibility for their safety or receive preliminary instructions

relating to the operation of the appliance.

• Do not let children play with the appliance.

• The appliance is not intended to be operated by means of an external

timer or separate remote-control system.

Disposal

• When disposing of packaging material: observe local legislation so that

the packaging may be reused.

• The European Directive 2012/19/EU on Waste Electrical and Electronic

Equipment (WEEE), requires that old household electrical appliances must

not be disposed of in the normal unsorted municipal waste stream. Old

appliances must be collected separately in order to optimise the recovery

and recycling of the materials they contain and reduce the impact on

human health and the environment.The crossed out “wheeled bin” symbol

on the product reminds you of your obligation, that when you dispose of

the appliance it must be separately collected.

Consumers should contact their local authority or retailer for information

concerning the correct disposal of their old appliance.
