Zigmund & Shtain CNS 024.60 BX [5/14] E n g l i s h

Zigmund & Shtain CNS 024.60 BX [5/14] E n g l i s h

3

380–415 V 3N~ Int. nominal current

by phases

30 cm hob 16 A

60 cm hob 11 A

> 60 cm hob 13 A

380–415 V 2N~

Int. nominal current by

phases

30 cm hob 16 A

60 cm hob 16 A

> 60 cm hob 19 A

This appliance is compliant with European

Directives 73/23/СЕЕ and 89/336/СЕЕ.

Recommendation: The hob must be installed by

a technician who will follow the manufacturer’s

instructions and diagrams.

1

2

Installation

Use

Identify the model of your hob (“a”, “b”, “c”,

“d”) by comparing the number and the layout

of the rings on your appliance with that shown

in the illustration.

1.1 Unpacking. Remove all packaging elements.

1.2 Mounting the hob into kitchen furniture.

Take into account the hob specifications

(1.2.1) as well as the dimensions of the

kitchen furniture to install it in (1.2.2, 1.2.3).

If you are not going to fit an oven beneath

the hob you must install a protective panel

in accordance with the specified dimensions

(1.2.4). Apply foamy insulation material along

the outer edges of the hob to properly seal it

(1.2.5). Turn the hob over and insert it into the

cutout (1.2.6). Secure the hob in the kitchen

furniture with the brackets supplied (1.2.7).

Do not use non-removable materials such as

silicone.

1.3 Connection to the mains.

• With 5 wires: a) dark blue, b) light blue, c)

brown, d) red, e) green and yellow (1.3.1).

• Used for the 230 V~ hob (1.3.2).

• Used for the 220–240 V~: see the table

(1.3.3).

• Total power: 60 cm hob 6.8 kW, > 60 cm

hob 7.8 kW.

220–240 V~ Int. nominal current by

phases

30 cm hob 16 A

60 cm hob 30 A

> 60 cm hob 34 A

• If the mains voltage exceeds 220–240 V~,

the appliance shall be connected as per

diagrams (1.3.3, 1.3.4).

220–240 V 3~ Int. nominal current

by phases

30 cm hob 16 A

60 cm hob 14 A

> 60 cm hob 16.5 A

0

Identification

If your hob is made of vitroceramics, you can

use clay, copper or stainless steel pans. Using

aluminium pans is not recommended since

they can stain the glass surface of the hob.

2.1 Selecting the cooking zone. There are

several rings available for putting pans on.

Choose the most suitable one depending

on the size of the pan.

2.2 Turning on the hob. Press and hold the

key for 3 seconds to turn on the hob;

0 signs of the different cooking spots will

be activated.

Note: To deactivate the locking system

preventing children from using the hob

press and hold the

or key and hold

for 3 seconds.

2.3 Turning on a ring. Turn on the ring you

have put the pan on by pressing the

corresponding

, , , key (2.3.1),

or press

(2.4.1).

Note: If choosing the key to press

takes more than 5 seconds, the hob

will automatically turn off as a safety

measure.

2.4 Selecting the power. Set it by pressing

or (2.4.1).

SPECIAL RINGS

2.5 Double ring, Triple ring (b, d). Once you
