20 DB268RMP/BD269RMP/BD269RGMP
280-8302-00
English
MP3 Mode Operations
3. Each time the button is pressed, scan play
turns on or off.
Display selection
1. You can choose the display type for MP3 CD
by pressing the [D] button.
To select the next type, press the [D] button
again.
The arrangement is shown below.
MAIN-1 ..... T02 02 : 18
(Track No., Play time)
MAIN-2 ..... F03 T05
(Folder No., track No.)
TITLE ..... FOLDER
(Folder)
∗ Refer to “Title display mode”
CLOCK ..... AM 10: 00
Title display mode
1. There are 5 types of display for the title
display mode.
2. To select the next type, press the [T] button
for less than 1 second.
The arrangement is shown below.
FOLDER
TRACK
ALBUM
ARTIST
TITLE
Folder Title
Track Title
Album tag
Artist Tag
Title Tag
After 2 seconds
3. The displayed item can be scrolled by
pressing the [T] button for more than 1
second.
4. If a MP3 file does not support for ID3 TAG,
the display will show “NO TAG”.
5. If a MP3 file encode with ID3 TAG header
but no consist of any TAG information, the
display will show nothing.
Notes:
• The folder name will be displayed as “ROOT”
which the file allocates in the root folder.
• The MP3 player decodes each file ID3 TAG ver 2
by default, if ID3 TAG ver 2 is unavailable, ID3
TAG ver 1 will be decoded.
• UNICODE ID3 (Chinese, Japanese and etc) is
not supported.
CD-DA/MP3 selection on
multisession CD
1. If a multisession CD which contains CD-DA
and MP3 files is being inserted, user can
select either CD-DA or MP3 files to be
played.
2. Default setting for files to be played on
multisession CD is CD-DA files.
3. Press the [BND] button for more than 1
second will toggle between selection of CD-
DA and MP3 files to be played.
4. When CD-DA type is selected, display will
show “M-S CD”. When MP3 type is selected,
display will show “M-S MP3”.
5. CD-DA/MP3 selection function can only be
performed in CD/MP3 mode. It will only
activate after re-insert CD. For example,
current setting is CD-DA type. Press [BND]
button for more than 1 second to set MP3
type. User has to eject CD and re-insert it
again as to play MP3 files.
6. Types of recording that can be played are as
follows.
Set to MP3
Disc
Set to CD
Setting
Mixed with CD and
MP3 type tracks
CD type track only
MP3 type track only
Play CD
Play CD
Play MP3
Play MP3
Play CD
Play MP3
7. When a mixed mode CD is loaded and CD is
set, the track to be played first is MP3 file
data and no sound is heard.
