Hitachi DS18DJLRC [6/12] Maintenance and inspection

● Regarding the temperatures and charging time of the battery.

The temperatures and charging time will become as shown in Table 2

Table 2

Charger

Battery

UC18YKSL

Charging voltage V 14.4V – 18V

Weight kg 0.35

Temperatures at which the battery can be

recharged

0oC – 50oC

Charging time for battery capacity, approx.

(At 20oC)

1.3 Ah

1.5 Ah

2.0 Ah

2.5 Ah

3.0 Ah

4.0 Ah

5.0 Ah

6.0 Ah

min.

120

150

180

Number of battery cells 4 – 10

How to use the LED light 7 10

Mounting the bit 8 10

Reversing the rotational direction 9 10

Switch operation 10 10

Using the bit holder 11 10

Selecting accessories ― 11

MAINTENANCE AND INSPECTION

1. Inspecting the tool

Since use of as dull tool will degrade eﬃ ciency and

cause possible motor malfunction, sharpen or replace

the tool as soon as abrasion is noted.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure that

they are properly tightened. Should any of the screws be

loose, retighten them immediately. Failure to do so could

result in serious hazard.

3. Maintenance of the motor

The motor unit winding is the very “heart” of the power

tool. Exercise due care to ensure the winding does not

become damaged and/or wet with oil or water.

4. Cleaning on the outside

When the driver drill is stained, wipe with a soft dry cloth

or a cloth moistened with soapy water. Do not use chloric

solvents, gasoline or paint thinner, for they melt plastics.

5. Storage

Store the driver drill in a place in which the temperature

is less than 40°C and out of reach of children.

NOTE

Storing lithium-ion batteries.

Make sure the lithium-ion batteries have been fully

charged before storing them.

Prolonged storage (3 months or more) of batteries with

a low charge may result in performance deterioration,

signiﬁ cantly reducing battery usage time or rendering

the batteries incapable of holding a charge.

However, signiﬁ cantly reduced battery usage time may

be recovered by repeatedly charging and using the

batteries two to ﬁ ve times.

If the battery usage time is extremely short despite

repeated charging and use, consider the batteries dead

and purchase new batteries.

NOTE

The recharging time may vary according to the ambient

temperature and power source voltage.

CAUTION

When the battery charger has been continuously used,

the battery charger will be heated, thus constituting

the cause of the failures. Once the charging has been

completed, give 15 minutes rest until the next charging.

4. Disconnect the charger’s power cord from the

receptacle.

5. Hold the charger ﬁ rmly and pull out the battery.

NOTE

Be sure to pull out the battery from the charger after use,

and then keep it.

CAUTION

○ If the battery is charged while it is heated because it has

been left for a long time in a location subject to direct

sunlight or because the battery has just been used, the

pilot lamp of the charger lights for 1 second, does not

light for 0.5 seconds (oﬀ for 0.5 seconds). In such a case,

ﬁ rst let the battery cool, then start charging.

○ When the pilot lamp ﬂ ickers (at 0.2-second intervals),

check for and take out any foreign objects in the charger’s

battery connector. If there are no foreign objects, it is

probable that the battery or charger is malfunctioning.

Take it to your authorized Service Center.

○

Since the built-in micro computer takes about 3 seconds to

conﬁ rm that the battery being charged with charger is taken

out, wait for a minimum of 3 seconds before reinserting it

to continue charging. If the battery is reinserted within 3

seconds, the battery may not be properly charged.

MOUNTING AND OPERATION

Action Figure Page

Removing and inserting the

battery

Charging 2 9

Tightening torque adjustment 3 9

Selecting the drill position 4 9

Selecting the impact position 5 9

Change rotation speed 6 9

0000Book_DS14DJL.indb 60000Book_DS14DJL.indb 6 2015/09/04 16:14:322015/09/04 16:14:32
