ENGLISH en
12
Impact drilling
Torque
Fig. A
1Keyless chuck
2 Additional handle
3 Slide switch (normal drilling, impact drilling) *
4S
lide switch (1st/2nd gear)
5 Button (switch between 'max. torque' and function
set at setting wheel (13)) *
6 Rotation selector switch (rotation setting,
transport lock) - both sides of the machine
7Bit depot *
8Belt hook *
9B
attery pack release button
10 Capacity indicator button
11 Capacity and signal indicator
12
Battery pack
13 Setting wheel (pulse function, torque control,
where applicable
'max. torque') *
14 LED lights
15 Trigger switch
*equipment-specific
7.1 Battery pack, capacity and signal display
Fig. B
Charge the battery pack before use.
If performance diminishes, recharge the battery
pack.
The ideal storage temperature is between 10 °C
and 30 °C.
7.2 Removing, replacing battery pack
Fig. C
7.3 Setting direction of rotation, transporting
safety device (switch-on lock) Fig. D
7.4 Selecting gear stage Fig. E
Only actuate slide switch (4) with the motor at
a standstill!
7.5 Setting for normal drilling, impact drilling
Fig. A
Press the slide switch (3).
7.6 Setting torque control, maximum torque,
pulse function
Do not work for long periods with pulse func-
tion switched on! (The motor can overheat.)
Machines with designation ...18 LTX
BL Quick...:
Fig. F
Turn the setting wheel (13) to switch on the pulse
function (button (5) flashes) or to switch on the
torque control (button (5) lights up continuously)
For maximum torque (drilling position), press the
button (5) (the button (5) is not illuminated). To acti-
vate the settings of setting wheel again: press the
button (5) again or turn the setting wheel.
Machines with designation ...18 LTX
Impuls/
Quick, ...18 LTX BL Impuls: Fig. G
Set the desired operating mode at the setting wheel
(13):
1...10 = torque control
Drill bit = maximum torque
Impuls = pulse function
7.7 Switching on/off, setting speed
Fig. A
Switching on, speed: Press the trigger (15). The
speed can be changed by pressing in the
trigger.
Switching off: release the trigger switch (15). Note:
The noise that the machine makes when it
switches off is due to the design (quick stop)
and has no influence on the function or the
service life of the machine.
7.8 Keyless chuck Fig. H
With a soft tool shank, retightening may be required
after a short period of operation.
Notes on
machines with the designation SB...
:
1. The ratchet sound which can possibly be heard
after opening the drill chuck is functional and is
switched off by a reverse rotation of the sleeve.
2. Clamping tool:
Turn sleeve (1) in direction "GRIP, ZU" until the
noticeable mechanical resistance has been
overcome.
Caution! The chuck is not yet fully tight-
ened! Keep turning the sleeve (it must "click"
when turning)) until it cannot be turned any
further - only now is the tool safely clamped.
Cleaning: From time to time, hold the machine
vertically with the keyless chuck facing
downwards and turn the sleeve fully in direction
"GRIP, ZU" and then turn fully in direction
"AUF, RELEASE". The dust collected falls from
the keyless chuck.
7.9 Unscrewing chuck Fig. I
Employ the same procedure when attaching the
chuck, except in reverse order.
7.10 Chuck with quick bit change system (for
BS 14.4 LTX Quick, BS 18 LTX Quick)
Fig. J
To remove: Push the interlock ring forward (a),
advance and pull off the chuck (b).
To mount: Push the interlock ring forward and
move the chuck as far as the limit stop on the drill
spindle.
6. Overview
7. Use
Nm
