Gardena PowerMax Li-40/32 05033-20.000.00 [11/17] Technical data
![Gardena PowerMax Li-40/32 05033-20.000.00 [11/17] Technical data](/views2/1368241/page11/bgb.png)
Problem Possible Cause Remedy
Error-LED
ß
E
on the charger is
flashing
Battery error.
v Remove the battery and
check that you use an original
GARDENA battery.
Error-LED
ß
E
on the charger lit
Temperature inside the charger
is to high.
v Contact the GARDENA service.
NOTE: For any other malfunctions please contact the GARDENA service department.
Repairs must only be done by GARDENA service departments or specialist dealers
approved by GARDENA.
7. TECHNICAL DATA
Battery Lawnmower Unit Value (Art. 5033)
Speed of rotation cutting
blade
R/min. 3,300
Cutting width cm 32
Cutting height adjustment
(12 positions)
cm 2 to 6
Volume of grass box l30
Weight kg 8.4
Sound pressure level L
PA
1)
Uncertainty k
PA
dB (A)
73
3
Sound power level L
WA
2)
:
measured/guaranteed
Uncertainty k
WA
dB (A) 86 / 86
0.59
Hand/arm vibration a
vhw
1)
Uncertainty k
a
m/s
2
1.64
1.5
System Battery / smart Battery Unit Value (Art. 9842 / 19090) Value (Art. 9843 / 19091)
Lawn area per battery charge
(up to)
m
2
280 450
Battery voltage V max. 40 (The maximum
initial noload voltage of the
battery is 40 V, the nominal
voltage is 36 V)
max. 40 (The maximum
initial noload voltage of the
battery is 40 V, the nominal
voltage is 36 V)
Battery capacity Ah 2.6 4.2
Battery charging time
approx. 80 % / 100 %
min. 65 / 90 105 / 140
Battery Charger Unit Value (Art. 9845)
Rated power W 100
Mains voltage V 230
Mains frequency Hz 50
24
GB
