1. INTRODUCTION

Thank you for purchasing this AVATAR product, which committed to the creation of extremely high-profile systems with no

loss of quality.

To ensure proper use, please read through this manual before using this product. It is especially important that you read and

observe CAUTION’s in this manual. Please keep the manual in a safe and accessible place for future reference.

1. Fasten the subwoofer properly when installing it in the vehicle. If the component is disconnected during driving, it may

cause serious damage to the passengers of the car or another vehicle.

2. Before installing the components, if possible store the product in the package in order to avoid accidental damage.

3. Be careful when installing and dismantling the subwoofer! Do not let the subwoofer drop to avoid damage of its moving

ATTENTION!!! The product may be operated at +5 to +40 °C. In case of moisture condensation, allow the product to dry.

8. When drilling or cutting out holes in the body of the car, make sure that there are no cables or any other important

construction elements under a selected area or inside it.

9. When stretching back the speaker cables make sure that they are not in contact with sharp edges or moving mechanical

devices. Make sure that they are firmly fixed and protected over the entire length.

10. The diameter of the speaker cables must be selected in accordance with the length and applied power.

11. Never stretch the cables outside the car and near the moving parts of the car. This can lead to destruction of the insulating

layer, short circuit and fire.

12. To protect the cables use rubber gaskets if the wire passes through a hole in the plate, or other similar materials if it lies

close to the parts exposed to heat.

Use these formulas to calculate the resistance of different connection types.

3. WIRING DIAGRAMS

CONNECTION OF TERMINALS

SERIE S C ONNECTI O N

Total re sistan c e = Ω Sub 1 + Ω Sub 2 + Ω S ub 3 ...
