Honeywell H4D8PR1 [3/4] Mp 4k ultra hd ir minidome ip camera

Honeywell H4D8PR1 [3/4] Mp 4k ultra hd ir minidome ip camera
* Some development may
be required in specific
user cases to support
some of these protocols
in the field as they
mature over time.
8 MP (4K Ultra HD) IR Minidome IP Cameras Technical Specifications
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
1/2.5" 8 MP Progressive CMOS
NUMBER OF PIXELS (H × V)
3840 × 2160
MINIMUM ILLUMINATION
0.1 lux (color)/0 lux (B/W) @
F1.6 (with IR LEDs on)
S/N RATIO
> 42 dB
ELECTRONIC SHUTTER
SPEED
Auto, Manual,
1/3(4) – 1/100,000 sec
IR DISTANCE
Up to 100 ft. (30 m), depending
on scene reflectance
DAY/NIGHT
Auto (ICR)/Color/BW
BACKLIGHT COMPENSATION
BLC/HLC/DWDR
WIDE DYNAMIC RANGE
Digital WDR (DWDR)
WHITE BALANCE
Auto/Manual/Natural/Street
Lamp/Outdoor/Regional Custom
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3DNR
PRIVACY MASKING
Up to 4 areas
CORRIDOR MODE
Yes
LENS
4.0 mm, Fixed lens, F1.6
ANGLE OF VIEW
Horizontal: 88°
Vertical: 48°
AUDIO/TWO-WAY
Line In/Out
ALARM INPUT/OUTPUT
1/1
ETHERNET
RJ45 (10/100BaseT)
IP SPECIFICATIONS
VIDEO COMPRESSION
H.265/H.264/MJPEG
Bit rate control (CBR and VBR)
RESOLUTION
16:9
8M (3840×2160) / WQHD
(2560×1440) / 3M
(2304×1296) / 1080p
(1920×1080) / 720p
(1280×720)
4:3
1.3M (1280×960)
OTHER
6M (3072×2048) /
4M (2688×1520) /
SXGA (1280×1024) /
D1 (704×576/704×480) /
CIF (352×288/352×240)
FRAME RATE
MAIN
STREAM
8M (3840×2160) 115 fps;
6M (3072×2048) 120 fps;
4M (2688×1520) / WQHD
(2560×1440) 125 fps;
3M (2304×1296) or lower
resolution at 125/30 fps
SECOND
STREAM
D1/CIF up to 25/30 fps
THIRD
STREAM
720p/D1 up to 25/30 fps
AUDIO COMPRESSION
G.726/G.711a/G.711u/AAC
AUDIO STREAM
Full duplex, simplex
SUPPORTED PROTOCOLS*
IPv4/v6, TCP/IP, UDP, RTP, RTSP,
HTTP, HTTPS, SSL, ICMP, FTP,
SMTP, DHCP, PPPoE, UPnP, IGMP,
SNMP, Bonjour, DNS, DDNS,
IEEE 802.1x, QoS, NTP, IP Filter,
Multicast, ONVIF
COMPATIBILITY
ONVIF Profile S and G
MAXIMUM USERS ACCESS
20 users
SUPPORTED WEB BROWSERS
Internet Explorer® (11.0+)
SUPPORTED OS
Windows® 7 32-bit/64-bit
SECURITY
Multiple user access levels with
enhanced password policy, IP
filtering, IEEE 802.1x, Strong
Digest authentication for Access
permission, Force to HTTPS with
secure protocol TLS1.2 only and
high strength encrypted algorithm
AES256, SSH/Telnet closed
MICRO SD
Up to 128 GB microSDHC card
MICRO SD FUNCTION
Event trigger recording
Continuous and scheduled
recording
Automatic recording when network
fails
LANGUAGES SUPPORTED
English, Japanese
ELECTRICAL
POWER SUPPLY
PoE (802.3af) Class 0/12 VDC
POWER CONSUMPTION
6.7 W max. (IR LEDs on)
MECHANICAL
DIMENSIONS
Ø110.0 mm × 81.0 mm
(Ø4.3" × 3.2")
PRODUCT WEIGHT
0.406 kg (0.9 lb.)
PACKAGE WEIGHT
0.531 kg (1.2 lb.)
CONSTRUCTION COLOR
White (RAL CODE 9003)
ENVIRONMENTAL
OPERATING TEMPERATURE
30°C to 60°C (22°F to 140°F)
RELATIVE HUMIDITY
Less than 95%, non-condensing
INGRESS PROTECTION
IP66
IMPACT RESISTANCE
IK10
REGULATORY
EMISSIONS
FCC Part 15B, EN55032
IMMUNITY
EN501304, EN55024
SAFETY
EU: EN609501
North America UL listed to UL/CSA
609501
ROHS
EN50581: 2012
