Honeywell HFD5PR1 [3/4] Megapixel fisheye ip camera
![Honeywell HFD5PR1 [3/4] Megapixel fisheye ip camera](/views2/1370859/page3/bg3.png)
* Some development may
be required in specific
user cases to support
some of these protocols
in the field as they
mature over time.
5 Megapixel Fisheye IP Cameras Technical Specifications
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
1/3" 5 MP Progressive CMOS
NUMBER OF PIXELS (H × V)
2592 × 1944
MINIMUM ILLUMINATION
0.01 lux (color)/0.001 lux (B/W)
@ F2.6
S/N RATIO
> 50 dB
ELECTRONIC SHUTTER SPEED
Auto, Manual,
1/3(4) – 1/100,000 sec
DAY/NIGHT
Auto (Electronic)/Color/BW
BACKLIGHT COMPENSATION
BLC/HLC/DWDR
WIDE DYNAMIC RANGE
Digital WDR (DWDR)
WHITE BALANCE
Auto/Manual
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3DNR
PRIVACY MASKING
Up to 4 areas
LENS
1.42 mm, Fixed fisheye lens, F2.6
ANGLE OF VIEW
Horizontal: 185°
AUDIO/TWO-WAY
1/1 Channel In/Out, Built-in Mic
ALARM INPUT/OUTPUT
1/1 Channel In/Out
ETHERNET
RJ45 (10/100BaseT)
IP SPECIFICATIONS
VIDEO COMPRESSION
H.264/MJPEG
Bit rate control (CBR and VBR)
RESOLUTION
4:3
5M (2560×1920) /
3M (2048×1520) /
UXGA (1600×1200) /
1.3M (1280×960)
OTHER
720p (1280×720) /
D1 (704×576/704×480) /
CIF (352×288/352×240)
FRAME RATE
MAIN STREAM
5M (3072×2048) at 112 fps
UXGA (1600×1200) at up to
25/30 fps
SECOND
STREAM
D1/CIF up to 25/30 fps
AUDIO COMPRESSION
G.711a/G.711u
IP SPECIFICATIONS (CON'T)
SUPPORTED PROTOCOLS*
IPv4/v6, TCP/IP, UDP, RTP, RTSP,
HTTP, HTTPS, SSL, ICMP, FTP,
SMTP, DHCP, PPPoE, UPnP, IGMP,
SNMP, Bonjour, DNS, DDNS, IEEE
802.1x, QoS, NTP, IP Filter
MAXIMUM USERS ACCESS
20 users
SUPPORTED WEB BROWSERS
Internet Explorer® (11.0+)
SUPPORTED OS
Windows® 7 32-bit/64-bit
MICRO SD
Up to 64 GB microSDHC card
MICRO SD FUNCTION
Event trigger recording
Continuous and scheduled
recording
Automatic recording when network
fails
LANGUAGES SUPPORTED
English, Japanese
ELECTRICAL
POWER SUPPLY
PoE (802.3af) Class 0/12 VDC
POWER CONSUMPTION
6.0 W max.
MECHANICAL
DIMENSIONS
Ø110.0 mm × 54.0 mm
(Ø4.3" × 2.1")
PRODUCT WEIGHT
0.25 kg (0.55 lb.)
CONSTRUCTION COLOR
White (RAL CODE 9003)
ENVIRONMENTAL
OPERATING TEMPERATURE
30°C to 40°C (22°F to 104°F)
RELATIVE HUMIDITY
Less than 95%, non-condensing
REGULATORY
EMISSIONS
FCC Part 15B, EN55032
IMMUNITY
EN501304; EN55024
SAFETY
EU: EN609501
North America UL listed to UL/CSA
609501
ROHS
EN50581: 2012
