DS-2CC502/512/592P(N)-FB

Specifications

Parameter Model

DS-2CC502P (N)-FB DS-2CC512P (N)-FB DS-2CC592P (N)-FB

Image Sensor 1/3 inch SONY CCD

Signal System PAL / NTSC

Effective Pixels

PAL: 500 (H) × 582 (V)

NTSC: 510 (H) × 492 (V)

PAL: 752 (H) × 582 (V)

NTSC: 768 (H) × 494 (V)

PAL: 752 (H) × 582 (V)

NTSC: 768 (H) × 494 (V)

Min. Illumination 0.1Lux @ F1.2

Electronic Shutter 1/50 (1/60)s to 1/100,000s

Lens 3.5 ~ 8mm (4 ~ 9mm optional)

Horizontal Resolution 420TVL 480TVL 540TVL

Synchronization Internal Synchronization

Video Output 1Vp-p Composite Output (75Ω/BNC)

S/N Ratio More than 48dB

BLC ON

Impact Protection IEC60068-27-5 test, Eh, 50J; EN50102, exceeding IK10.

Working Temperature -10 ~ 60℃℃

Power Supply 12VDC, ±10%

Power Consumption 2W MAX

Dimensions (mm)

φ140 × 92

(φ5.55” × 3.65”)

Weight

660g

(1.45lbs)

Dimensions
