AXIS P1343/-E/AXIS P1344/-E - Accessing the Camera

The Live View page

If your network camera has been customized to meet specific requirements the buttons and other items described below may

or may not be displayed on the Live View page. The following provides an overview of each available button:

General controls

AXIS Media Control toolbar

The AXIS Media Control viewer toolbar is available in Internet Explorer only. See AXIS Media Control (AMC), on page 14 for

more information. The toolbar displays the following buttons:

View size – Click to scale the image down to 800 pixels wide or to full scale. Only available on

AXIS P1344/-E in MJPEG.

The Stream Profile drop-down list allows you to select a customized or pre-programmed stream profile on

the Live View page. Stream profiles are configured under Video & Audio > Stream Profiles, see Stream

Profiles, on page 19 for more information.

Pulse – Click this button to activate the output for a defined period of time, such as switching a light on

for 20 seconds.

Active/Inactive – Click these buttons to manually start and stop a connected device - e.g. switch a light

on/off.

The Manual trigger buttons can trigger an event directly from the Live View page. This button is config-

ured under Events.

The Snapshot button saves a snapshot of the video image on display. Right-click on the video image to

save it in JPEG format on your computer. This button is primarily intended for use when the AXIS Media

Control viewer toolbar is not available.

Audio clip - Audio clips can be played when an event occurs or manually from the Live View page.

The Play button connects to the Axis product and starts playing a media stream.

The Stop button stops the video stream being played.

The Snapshot button takes a snapshot of the current image. The location where the image is saved can be speci-

fied in the AMC Control Panel.

Click the View Full Screen button and the video image will fill the entire screen. Press Esc (Escape) on the com-

puter keyboard to cancel full screen view.

The Record button is used to record the current video stream. The location where the recording is saved can be

specified in the AMC Control Panel.
